The TG1006 is a 10MHz generator that uses DDS frequency generation to give greater accuracy and stability, and to cover a wider frequency range. As well as being a high performance function generator, the unit also features a wide range sweep mode and an autoranging 120MHz frequency counter. The generator outputs sine, square and triangle waveforms and there are AM, FSK and frequency list modulation modes.

• Exceptional accuracy and stability
• High spectral purity
• Low phase noise
• Excellent frequency agility
• Simultaneous display of frequency and amplitude/offset
• Storage for up to 10 frequencies in non-volatile memory
• Input control by numeric keypad or spin wheel

The Aim-TTiTG2000 breaks new ground by offering a high quality DDS function generator at a significantly lower price. DDS (direct digital synthesis) is a technique for generating waveforms digitally using a phase accumulator, a look-up table and a DAC. The accuracy and stability of the resulting waveforms is related to that of the crystal master clock. When correctly engineered, the DDS generator offers not only exceptional accuracy and stability but also high spectral purity, low phase noise and excellent frequency agility.

Unlike some other generators which only provide digital control of frequency, every function is digitally controlled enabling complete instrument set-ups to be stored, or full remote control to be implemented. The Aim-TTiTG2000 can generate waveforms between 0.001Hz and20MHz with a resolution of six digits and a one year accuracy better than 10ppm. The TG1000 has a 10MHz limit.

Amplitude is variable between 5mV and 20V pk-pk from a source impedance of 50Ω or 600Ω. Unlike many generators, the waveform quality remains excellent over the full amplitude range. The Aim-TTiTG2000 also includes both an RS-232 interface and USB interface. These interfaces can be used for remote control of all of the instrument functions and for remotely storing instrument set-ups.

• 0.001Hz to 10MHz or 20MHz frequency range
• 6 digits or 1mHz resolution
• 1ppm stability and 10ppm one year accuracy
• Low distortion, high spectral purity sine waves
• Internal phase continuous sweep, lin or log
• AM, FSK, gated and tone switching modes
• 5mV to 20V pk-pk from 50Ω or 600Ω
• Storage for multiple instrument set-ups
• USB and RS232 Interfaces
• Low cost
• Manufacturers part no. Aim-TTi TG2000

The TG2511A is a low cost, high performance DDS function generator that also incorporates full pulse generator and arbitrary generator capabilities. A high resolution graphics LCD provides representative waveform displays, and arbitrary waveforms can be saved and loaded via the front mounted USB Flash drive socket, or via the USB and LAN (Ethernet) interfaces.

The generator offers very fast edge speeds of better 13ns on the TG2511A, but the edges can be slowed down to simulate slower pulses. Rise and fall times are independently variable in the range 10ns to 40µs on the TG2511A or can be linked so that both edge speeds are the same.

• 1µHz to 25MHz range; 1µHz resolution
• True pulse generator with variable delay and variable rise/fall
• Arbitrary waveforms of up to 128K points at up to 125MS/s
• Standard waveforms include sine, square, ramp, pulse, sin(x)/x, noise, exponential and logarithmic
• Waveform storage using USB flash drives
• Large graphic LCD with simultaneous text and waveform display
• Comprehensive internal and external digital modulations including AM, FM, PM, PWM and FSK
• Waveform Manager Plus for Windows software included
• Programmable via USB and LAN (LXI) interfaces; GPIB optional
• Manufacturers part no. Aim-TTi TG2511A

This unit is a 25MHz state-of-the-art DDS-based function generator, with two identical channels that can be used linked or as completely independent generators. The advanced unit can operate as a function generator, arbitrary waveform generator, or pulse generator. There is a comprehensive range of standard waveforms and also arbitrary waveforms of up to 128K points and 125MS/s. The unit functions as a true pulse generator, with variable delay and variable rise/fall. Additionally, a full range of external and internal digital modulation types is provided. The unit has a large graphic LCD with simultaneous text and waveform display. Waveform storage and transfer is possible via USB, and instrument set-up and storage is also stored in non-volatile memory. The unit is programmable via USB, GPIB and LXI compliant LAN interfaces.

• Full range output 20mV to 20V output from 50Ω
• Internal or external modulation
• Multifunction aux-out
• Coupled and tracking modes
• Inter-channel phase offset
• Waveform manager plus for windows editing software
• Compact ½ 2U casing with protective buffers and handle

This function generator from Aim-TTi provides very high waveform quality under all conditions and represents the state-of-the-art in low-cost analogue function generators.

• 0.03Hz to 3MHz frequency range
• Fast and accurate frequency measurement
• Wide range level control with 2mV to 20V peak to peak amplitude
• Simultaneous display of frequency and amplitude
• RMS, peak to peak or DC offset amplitude display
• Very high waveform quality at all frequencies and levels
• Variable symmetry with constant frequency
• Variable DC offset with zero detent
• 1000:1 frequency change by vernier or sweep voltage
• Auxiliary TTL/CMOS output
• External seven digit 120MHz frequency counter
• Precision internal linear or logarithmic variable sweep generator
• Internal or external amplitude modulation
• Size 260 x 235 x 88mm
• Complies with EN61010-1 and EN61326
• Aim-TTi TG300 series

The Aim-TTi TGxx11 Series represents the state-of-the-art in DDS based function generators. The 50MHz TG5011A significantly outperforms other generators in its price range, not just because of its frequency range, but because of its all round performance and features.

The TG2511A incorporates a similar feature set at a still lower cost and represents exceptional value for those with lower frequency requirements.The TG5011A out-performs other generators in its price range by offering both sine and square waves up to 50MHz. The lower cost TG2511A operates to 25MHz. The frequency of these waveforms can be set with up to 14 digits or one micro hertz of resolution.

The DDS based frequency generation system uses a TCXO time base oscillator with a stability of 1ppm. On the TG5011A, the pulse period can be set between 80ns and 2000 seconds. (0.5mHz to 12.5MHz) with a resolution of 14 digits or 1µHz.

• 0.001mHz to 50MHz/25MHz range; 1uHz resolution
• True pulse generator with variable delay and variable rise/fall
• Arbitrary waveforms of up to 128K points at up to 125MS/s
• Standard waveforms include sine, square, ramp, pulse, sin(x)/x, noise, exponential and logarithmic
• Waveform storage using USB flash drives
• Large graphic LCD with simultaneous text & waveform display
• Comprehensive internal and external digital modulations including AM, FM, PM, PWM and FSK
• Waveform Manager Plus for Windows software included
• Programmable via USB & LAN (LXI) interfaces; GPIB optional
• Manufacturers part no. Aim-TTi TG5011A

This unit is a 50MHz state-of-the-art DDS-based function generator, with two identical channels that can be used linked or as completely independent generators. The advanced unit can operate as a function generator, arbitrary waveform generator, or pulse generator. There is a comprehensive range of standard waveforms and also arbitrary waveforms of up to 128K points and 125MS/s. The unit functions as a true pulse generator, with variable delay and variable rise/fall. Additionally, a full range of external and internal digital modulation types is provided. The unit has a large graphic LCD with simultaneous text and waveform display. Waveform storage and transfer is possible via USB, and instrument set-up and storage is also stored in non-volatile memory. The unit is programmable via USB, GPIB and LXI compliant LAN interfaces.

• Full range output 20mV to 20V output from 50Ω
• Internal or external modulation
• Multifunction aux-out
• Coupled and tracking modes
• Inter-channel phase offset
• Waveform manager plus for windows editing software
• Compact ½ 2U casing with protective buffers and handle

A 50MHZ dual channel advanced, high performance pulse and universal generator that is a true pulse generator as well as a noise generator and 800MS/s 16-bit arbitrary/function generator with 16 waveform types. There is a wide range of pulse modulations and the unit has internally or externally triggered burst or gate operation. An intuitive and comprehensively equipped user interface makes setup and operation easy and the unit is programmable via USB or LAN. Typical applications for this unit include stress testing, clock frequency simulation, data sequencing patterns, asynchronous pulse signal conditioning, op amp slew rate and asymmetrical, propagation delay testing.

• 256 x 112 pixel backlit monochrome display
• Universal power input
• Low jitter
• High drive capability
• Front panel flash drive interface
• Driver software supplied

The TGR6000 is a low-cost RF signal generator with a maximum frequency of 6GHz. It is intended for CW (carrier wave) applications where modulation is not required, and avoids the costs associated with adding modulations.

Low phase noise is matched by low leakage, low residual FM and spurii. The internal timebase has a 1ppm stability, and an external frequency reference can be used for higher precision.

The TGR6000 incorporates an advanced stepped sweep system which allows both frequency and amplitude to be swept. The sweep can be defined in terms of start and stop frequency/amplitude points with linear or logarithmic interpolation between them. The total number of points can be set from 2 to 1000 and the dwell time between points can be set from 10ms up to 10s.

Sweeps can be triggered manually, from an internal timer or from the remote interfaces. If required, each point within the sweep can be stepped via a trigger event rather than a fixed time. In List Sweep mode, the sweep is defined by a table of up to 1000 frequency/amplitude points which can be stepped between either by trigger events or by an individual dwell time for each point.

This system provides the flexibility to generate changes in frequency and amplitude to match virtually any required test pattern.Lists can be generated within the instrument or on a PC and downloaded via the interfaces. Up to 16 user lists can be stored permanently within the instrument’s memory.

Frequency and level can be entered directly from the keyboard in whichever units are preferred. Alternatively values can be changed in user defined increments using the spin wheel or up/down keys.

The four line display has soft key functionality for setting up more complex functions such as sweep lists.

• 10MHz to 6000MHz frequency range
• Accuracy better than 1ppm over 15°C to 30°C
• Ageing better than 1ppm over one year
• External frequency reference input
• Low phase noise and low leakage
• -110dBm to +7dBm amplitude, 0.1dB steps
• Amplitude entry in dBm, μV / mV, or dBμV
• User compensation tables for specific test set-ups
• Fast stepping sweep with dwell times down to 10ms
• Internal or externally triggered sweep, lin or log, up or down
• List sweep of up to 1000 points of amplitude vs frequency
• Storage for 12 generator set-ups and 16 sweep lists
• Compact half-rack 2U casing uses minimum bench space
• Full remote control through RS232, USB, LAN or GPIB
• Significantly lower cost than other 6GHz generators
• Manufacturers part no. Aim-TTi TGR6000

The GW Instek AFG-3000 Series are arbitrary waveform generators designed for industrial, scientific research and educational applications.

The AFG-3000 Series also provides a high 16-bit resolution, 200MSa/s sample rate and a 1M memory depth for editing arbitrary waveforms directly through the intuitive user interface. The Direct Waveform Reconstruction (DWR) function enables users to directly import waveforms from a GDS-2000 Series oscilloscope to the AFG-3000 via USB host, allowing users to edit waveforms and enhance measurement efficiency. In addition, the AFG-3000 Series has switchable 50Ohm and Hi-Z Impedances, built-in On-Screen Help for operation conveniently.

Complete parameter settings and waveform can be displayed through 4.3-inch high-resolution TFT LCD. Through USB, RS-232, and GPIB, user can use dedicated PC software or IEEE488.2 commands to edit waveforms.

• Wide frequency range from 1uHz to 80MHz
• High 200MSa/s sampling rate
• 16-bit Amplitude resolution
• Output from any section of 1M-point-long waveforms
• 4.3 inch high resolution LCD display/on-screen help/impedance switch
• Four ways to generate arbitrary waveforms: front panel operation
• CSV file uploading, Direct Waveform Reconstruction (DWR), arbitrary
• Waveform editing PC software
• USB, RS-232, GPIB interface support
• Manufacturers part no. GW Instek AFG-3081

The GW Instek GAG-810 provides a convenient solution for low frequency (<1MHz) signal generation, specifically for audio bandwidth. The GAG-810 has a intuitive and simple panel interface providing quick frequency and amplitude adjustment, with dial/key shortcuts to different ranges.

Square wave generation covers digital application in addition to the traditional analog using sine waves. Distortion is kept at minimum level, especially at the audible frequency range: 0.02% or less distortion factor for 500Hz to 20kHz. The external synchronization signal input helps collaborate with other measurement devices.

• Frequency from 10Hz to 1MHz
• 0.02% Low Sine Wave Distortion
• 6-Step Output Attenuator
• EXT SYNC Function
• Manufacturers part no. GW Instek GAG-810

The GW Instek GFG-8255A offers a complete solution in generating signals at the 3MHz/5MHz ranges. This model is embedded with standard functions such as TTL/CMOS/ramp output, external voltage controlled frequency (VCF), and built-in 6-digit counter.

Further versatility of Logarithmic and Linear sweep is added into the GW Instek GFG-8255A. All these integrated functions and user-friendly operations of the GW Instek GFG-8255A are made to accommodate the applications in audio response testing, vibration testing, servo system evaluation, ultra sound application, etc. The GW Instek GFG-8255A Function Generator is a stable low distortion instrument, which will generate signals in the frequency range up to 5MHz.

• Frequency Range: 0.5Hz to 5MHz
• Waveforms: sine, triangle, square, ramp, TTL and CMOS output
• External Voltage Controlled Frequency (VCF) function
• Two-Steps (-20dBx2) and variable attenuator
• Built-In 6 Digits Counter with INT/EXT Function up to 150MHz
• INT/EXT AM/FM Modulation
• GCV Output for Synchronization
• Manufacturers part no. GW Instek GFG-8255A

The GW Instek SFG-1003 is an economic function generator with high accuracy and high stability output, are designed based on the DDS (Direct Digital Synthesized) technology embedded in a large scale FPGA.

The 3MHz frequency range and the output waveform selection of Sine, Square, Triangle and TTL available in the GW Instek SFG-1003 adequately provide the fundamental functions to ensure high confidence in test results. The DDS technology at an affordable price gives a high value solution to the users who need a signal source for accurate but simple measurement applications.

• DDS Technique and FPGA Chip Design
• Frequency Range: 0.1Hz to 3MHz
• High Frequency Accuracy: ±20ppm
• High Frequency Stability: ±20ppm
• Max. Frequency Resolution: 100mHz
• Low Distortion Sine Wave: -55dBc, 0.1Hz to 200kHz
• Manufacturers part no. GW Instek SFG-1003

The SFG GW Instek SFG-1013 is an economic function generator with high accuracy and high stability output, that has been designed based on the DDS (Direct Digital Synthesized) technology embedded in a large scale FPGA.

The 3MHz frequency range and the output waveform selection of Sine, Square, Triangle and TTL available in the GW Instek SFG-1013 adequately provide the fundamental functions required to ensure high confidence in test results. The DDS technology at an affordable price gives a high value solution to the users who need a signal source for accurate but simple measurement applications.

• DDS Technique and FPGA chip design
• Frequency range: 0.1Hz to 3MHz
• High frequency accuracy: ±20ppm
• High frequency stability: ±20ppm
• Max. frequency resolution: 100MHz
• Low distortion sine wave: -55dBc, 0.1Hz to 200kHz
• Voltage display
• Manufacturers part no. GW Instek SFG-1013

The Rigol DG1022Z is a high performance 25MHz multifunctional generator that combines a function generator, arbitrary waveform generator, noise generator, pulse generator, harmonics generator, analog/digital modulator and frequency counter.

The unit is portable and has the functions and performance to be the ideal choice for use in a wide variety of applications such as R & D, production, test, education, etc. There are two full function independent channels and the device can produce both basic waveforms and 160 kinds of arbitrary waveforms, including: Sinc, exponential rise, exponential fall, ECG, Gauss, HaverSine, Lorentz, dual-tone, etc.

• 25MHz Multifunction generator
• Sample rate 200MS/s
• Universal voltage input 100 to 240V AC
• 160 built-in pre-edited waveforms
• Intuitive arbitrary waveform editing software
• Full modulation supported
• 3.5in TFT LCD 320 x 240 pixels display
• SiFi (Signal Fidelity) for 100% waveform replication
• USB and LAN interfaces
• IP2X Protection
• Supplied with mains cable, USB cable, BNC cable, quick guide, resource CD
• Rigol DG1022Z

This 30MHz waveform generator from Rigol is a multi-functional generator that combines many functions in one, including function generator, arbitrary waveform generator, noise generator, pulse generator, harmonics generator, analogue/digital modulator and counter. As a multi-functional, high performance and portable generator, it will be a new selection in education, R&D, production, test etc.

• Innovative SiFi (Signal Fidelity): generate arb waveform point-by-point, restore signal distortionless, precisely adjustable sample rate and low jitter (200ps)
• Arbitrary waveform memory: 8Mpts (standard), 16Mpts (optional)
• Standard 2 full functional channels can be used as two independent generators
• ±1ppm frequency stability, -125dBc/Hz phase noise
• Built-in 8 orders harmonics generator
• Built-in 7 digits/s full function frequency counter with 200MHz bandwidth
• Up to 160 built-in waveforms
• 200MSa/s sample rate, 14bits vertical resolution
• Convenient arbitrary waveform editing interface
• Versatile modulation types: AM, FM, PM, ASK, FSK, PSK and PWM
• Standard waveform summing function
• Standard channel track function
• Standard interfaces: USB Host and Device, LAN (LXI Core Device 2011)
• 3.5in TFT colour display
• Manufacturer's part DG1032Z

This 30MHz waveform generator from Rigol is a multi-functional generator that combines many functions in one, including function generator, arbitrary waveform generator, noise generator, pulse generator, harmonics generator, analogue/digital modulator and counter. As a multi-functional, high performance and portable generator, it will be a new selection in education, R&D, production, test etc.

• Innovative SiFi (Signal Fidelity): generate arb waveform point-by-point, restore signal distortionless, precisely adjustable sample rate and low jitter (200ps)
• Arbitrary waveform memory: 8Mpts (standard), 16Mpts (optional)
• Standard 2 full functional channels can be used as two independent generators
• ±1ppm frequency stability, -125dBc/Hz phase noise
• Built-in 8 orders harmonics generator
• Built-in 7 digits/s full function frequency counter with 200MHz bandwidth
• Up to 160 built-in waveforms
• 200MSa/s sample rate, 14bits vertical resolution
• Convenient arbitrary waveform editing interface
• Versatile modulation types: AM, FM, PM, ASK, FSK, PSK and PWM
• Standard waveform summing function
• Standard channel track function
• Standard interfaces: USB Host and Device, LAN (LXI Core Device 2011)
• 3.5in TFT colour display
• Manufacturer's part DG1032Z

This 60MHz waveform generator from Rigol has been manufactured to a very high standard and is equipped with a host of rich features, including the arbitrary waveform function and built-in 150 waveforms, plus abundant analog and digital modulation functions. Other features include the standard identical 2 channels with frequency and phase coupling, various sweep modes, noise and burst modes, up to 16 orders customized harmonic generation functions, standard high resolution counter function and the statistic analysis function of counter.

• 500MSa/s sample rate, 14 bits vertical resolution
• Dual channel outputs with identical performance
• 2ppm high-frequency stability
• -115dBc/Hz low phase noise
• Versatile analog and digital modulation functions
• Built-in 150 waveforms
• Built-in 7digits/s, 200MHz counter
• 16th harmonic generation function (Std.)
• Powerful waveform editing PC software
• Connectivity: USB host and device, LAN
• 7in LCD display (800 x 480)
• Manufacturer's part DG4062

This 100MHz waveform generator from Rigol has been manufactured to a very high standard and is equipped with a host of rich features, including the arbitrary waveform function and built-in 150 waveforms, plus abundant analog and digital modulation functions. Other features include the standard identical 2 channels with frequency and phase coupling, various sweep modes, noise and burst modes, up to 16 orders customized harmonic generation functions, standard high resolution counter function and the statistic analysis function of counter.

• 500MSa/s sample rate, 14 bits vertical resolution
• Dual channel outputs with identical performance
• 2ppm high-frequency stability
• -115dBc/Hz low phase noise
• Versatile analog and digital modulation functions
• Built-in 150 waveforms
• Built-in 7digits/s, 200MHz counter
• 16th harmonic generation function (Std.)
• Powerful waveform editing PC software
• Connectivity: USB host and device, LAN
• 7in LCD display (800 x 480)
• Manufacturer's part DG4102

The Tektronix AFG1022 is an Arbitrary Function Generator that provides waveform generation tools with the best price performance ratio. It offers dual-channel operation with up-to 10Vp-p output amplitude and a bandwidth of 25MHz.

The four run modes, 50 built-in frequently-used waveforms and the built-in 200MHz frequency counter cover most waveform generation needs in your experiment and test jobs. The 3.95-inch TFT LCD, short-cut buttons, USB interface and PC software provide the most intuitive ways to configure the instrument.

Applications: Electric and Electronics Experiments, Communications Experiments, Sensor Simulation and Functional Test.

• Dual-channel, 25MHz sine waves and 12.5MHz square/pulse wave
• 125MS/s sampling rate and 14-bit vertical resolution enable great signal fidelity
• 1mVp-p to 10Vp-p output amplitude into 50Ω over the whole frequency range
• Intuitive user interface shortens the learning curve for students and other users
• 14 bits, 125MS/s arbitrary waveforms with 8k points record length
• 64 Mbyte internal non-volatile memory for arbitrary waveform storage
• Standard USB host / device for memory expansion and remote control
• Continuous, sweeping, burst, and modulation modes covers most requirements for students and other users
• Built-in 200MHz counter with 6-digit resolution
• Compact form factor for stacking on other bench instruments to save valuable bench space
• Free ArbExpress makes user defined waveform editing extremely easy
• Compatible with TekSmartLab
• Manufacturer's 5-year warranty
• Tektronix type AFG1022

The Tektronix AFG1062 is an Arbitrary Function Generator that provides waveform generation tools with the best price performance ratio. It offers dual-channel operation with up-to 10Vp-p output amplitude and a bandwidth of 60MHz.

The four run modes, 50 built-in frequently-used waveforms and the built-in 200MHz frequency counter cover most waveform generation needs in your experiment and test jobs. The 3.95-inch TFT LCD, short-cut buttons, USB interface and PC software provide the most intuitive ways to configure the instrument.

Applications: Electric and Electronics Experiments, Communications Experiments, Sensor Simulation and Functional Test.

• Dual-channel, 60MHz sine waves and 30MHz square/pulse wave
• 300MS/s sampling rate and 14-bit vertical resolution enable great signal fidelity
• 1mVp-p to 10Vp-p output amplitude into 50Ω over the whole frequency range
• Intuitive user interface shortens the learning curve for students and other users
• 300MS/s arbitrary waveforms with 1M points record length
• 64 Mbyte internal non-volatile memory for arbitrary waveform storage
• Standard USB host / device for memory expansion and remote control
• Continuous, sweeping, burst, and modulation modes covers most requirements for students and other users
• Built-in 200MHz counter with 6-digit resolution
• Compact form factor for stacking on other bench instruments to save valuable bench space
• Free ArbExpress makes user defined waveform editing extremely easy
• Compatible with TekSmartLab
• Manufacturer's 5-year warranty
• Tektronix type AFG1062

The Tektronix AFG2021 Arbitrary Function Generator gives you the power to create the signals you need at an entry-level price.

With 20 MHz bandwidth, 14-bit resolution, and 250 MS/s sample rate, you can generate all manner of signals from complex serial data streams to simple audio frequencies or clock signals to the output of an airbag sensor during a crash.

With 12 standard waveforms, modulation capability, and a built-in noise generator, you can quickly create the signal you need to thoroughly exercise your designs.

• The innovative user interface reduces setup and evaluation time with direct access to frequently used functions and parameters
• The internal 4 × 128 kS memory and the USB memory expansion capability provide substantial capacity for defining complex waveforms
• USB remote control port and USB flash drive port are included. GPIB and LAN interfaces are available as an option
• Built-in Modulation, Noise Generator, Burst, and Sweep modes for greater versatility
• Built-in waveforms provide quick access to commonly used signals
• 3.5 inch colour screen displays both graphical and numeric waveform information simultaneously
• Menu and online help in 8 languages
• 2U height and half-rack width fits both benchtop and rack-mounted applications
• ArbExpress software makes waveform editing and downloading extremely easy
• SignalExpress software combines Tektronix bench instruments into a low-cost solution for automatic testing

The Tektronix AFG3011C is a Single-Channel Arbitrary Function Generator that is unmatched in performance, versatility, intuitive operation, and affordability. This makes the AFG3011C Function, Arbitrary Waveform, and Pulse Generator, one of the most useful instruments in the industry.

The user can choose from 12 different standard waveforms. Arbitrary waveforms can be generated up to 128K in length at high sampling rates. On pulse waveforms, leading and trailing edge time can be set independently.

External signals can be connected and added to the output signal. The AFG3011C is a single channel model and features a highly stable time base with only ±1ppm drift per year.

The large colour TFT LCD screen shows all relevant waveform parameters and graphical waveshape at a single glance. This gives full confidence in the signal settings and lets you focus on the task at hand. Shortcut keys provide direct access to frequently used functions and parameters. Others can be selected conveniently through clearly structured menus. This reduces the time needed for learning and re-learning how to use the instrument.

What's in the Box?AFG3011C Single Channel Function GeneratorQuick-start user manualPower CordUSB CableCD-ROM with specifications and performance verification manualProgrammer manualService manualLabView and IVI driversCD-ROM with ArbExpress softwareNIST-traceable calibration certificate

• Amplitude up to 20Vp-p into 50Ω Loads
• 5.6 inch Colour TFT LCD display for full confidence in settings and waveform shape
• Multilanguage and intuitive operation saves setup time
• Pulse waveform with variable edge times
• AM, FM, PM, FSK, PWM
• Sweep and burst
• USB Connector on front panel for waveform storage on memory device
• USB, GPIB, and LAN
• LabVIEW and LabWindows/IVI-C drivers
• Supplied with 1-Channel
• Supplied with 8MHz Analogue Bandwidth
• Manufacturer's part: Tektronix AFG3011C

The Tektronix AFG31021 is a high-performance arbitrary function generator (AFG) with built-in arbitrary waveform generation, real-time waveform monitoring, and the largest touchscreen on the market.

This product features basic and advanced modes making it suitable for a range of operators. In basic mode this unit can generate traditional functions and arbitary waveforms direct from the touchscreen interface. In advanced mode it is possible to sequence up to 256 waveforms and define the output sequence. Additionally advanced mode uses variable sample rate technology. Every sample in a waveform is output once and only once in each cycle, synchronised to the sample rate. Since there is no skipping or repetition, all details in the waveforms are kept. This feature is very useful for applications in which signal fidelity is extremely critical, such as IQ modulation and pulse train generation.

• Single channel 1µHz to 25MHz Sine frequency range.
• Patented InstaView™ technology enables engineers to see the actual waveform at the Device Under Test (DUT) in real time, without the need of an oscilloscope and probe, eliminating the uncertainty caused by mismatched impedance.
• Sequencing option adds the ability to program long, complex waveforms with up to 256 steps.
• The 9-inch capacitive touch screen works like a smart phone and has short-cuts to frequently used settings.
• Built-in ArbBuilder lets you create and edit arbitrary waveforms on the instrument, eliminating the need to connect to a PC.
• Outputs are protected from over voltage and current to minimize potential instrument damage.
• Built-in Double Pulse Test application to generate voltage pulses with varying pulse widths onto the DUTs.

The Tektronix AFG31022 is a high-performance arbitrary function generator (AFG) with built-in arbitrary waveform generation, real-time waveform monitoring, and the largest touchscreen on the market.

This product features basic and advanced modes making it suitable for a range of operators. In basic mode this unit can generate traditional functions and arbitary waveforms direct from the touchscreen interface. In advanced mode it is possible to sequence up to 256 waveforms and define the output sequence. Additionally advanced mode uses variable sample rate technology. Every sample in a waveform is output once and only once in each cycle, synchronised to the sample rate. Since there is no skipping or repetition, all details in the waveforms are kept. This feature is very useful for applications in which signal fidelity is extremely critical, such as IQ modulation and pulse train generation.

• Twin channel 1µHz to 25MHz Sine frequency range.
• Patented InstaView™ technology enables engineers to see the actual waveform at the Device Under Test (DUT) in real time, without the need of an oscilloscope and probe, eliminating the uncertainty caused by mismatched impedance.
• Sequencing option adds the ability to program long, complex waveforms with up to 256 steps.
• The 9-inch capacitive touch screen works like a smart phone and has short-cuts to frequently used settings.
• Built-in ArbBuilder lets you create and edit arbitrary waveforms on the instrument, eliminating the need to connect to a PC.
• Outputs are protected from over voltage and current to minimize potential instrument damage.
• Built-in Double Pulse Test application to generate voltage pulses with varying pulse widths onto the DUTs.

The Tektronix AFG31051 is a high-performance arbitrary function generator (AFG) with built-in arbitrary waveform generation, real-time waveform monitoring, and the largest touchscreen on the market.

This product features basic and advanced modes making it suitable for a range of operators. In basic mode this unit can generate traditional functions and arbitary waveforms direct from the touchscreen interface. In advanced mode it is possible to sequence up to 256 waveforms and define the output sequence. Additionally advanced mode uses variable sample rate technology. Every sample in a waveform is output once and only once in each cycle, synchronised to the sample rate. Since there is no skipping or repetition, all details in the waveforms are kept. This feature is very useful for applications in which signal fidelity is extremely critical, such as IQ modulation and pulse train generation.

• Single channel 1µHz to 50MHz Sine frequency range.
• Patented InstaView™ technology enables engineers to see the actual waveform at the Device Under Test (DUT) in real time, without the need of an oscilloscope and probe, eliminating the uncertainty caused by mismatched impedance.
• Sequencing option adds the ability to program long, complex waveforms with up to 256 steps.
• The 9-inch capacitive touch screen works like a smart phone and has short-cuts to frequently used settings.
• Built-in ArbBuilder lets you create and edit arbitrary waveforms on the instrument, eliminating the need to connect to a PC.
• Outputs are protected from over voltage and current to minimize potential instrument damage.
• Built-in Double Pulse Test application to generate voltage pulses with varying pulse widths onto the DUTs.

The Tektronix AFG31052 is a high-performance arbitrary function generator (AFG) with built-in arbitrary waveform generation, real-time waveform monitoring, and the largest touchscreen on the market.

This product features basic and advanced modes making it suitable for a range of operators. In basic mode this unit can generate traditional functions and arbitary waveforms direct from the touchscreen interface. In advanced mode it is possible to sequence up to 256 waveforms and define the output sequence. Additionally advanced mode uses variable sample rate technology. Every sample in a waveform is output once and only once in each cycle, synchronised to the sample rate. Since there is no skipping or repetition, all details in the waveforms are kept. This feature is very useful for applications in which signal fidelity is extremely critical, such as IQ modulation and pulse train generation.

• Twin channel 1µHz to 50MHz Sine frequency range.
• Patented InstaView™ technology enables engineers to see the actual waveform at the Device Under Test (DUT) in real time, without the need of an oscilloscope and probe, eliminating the uncertainty caused by mismatched impedance.
• Sequencing option adds the ability to program long, complex waveforms with up to 256 steps.
• The 9-inch capacitive touch screen works like a smart phone and has short-cuts to frequently used settings.
• Built-in ArbBuilder lets you create and edit arbitrary waveforms on the instrument, eliminating the need to connect to a PC.
• Outputs are protected from over voltage and current to minimize potential instrument damage.
• Built-in Double Pulse Test application to generate voltage pulses with varying pulse widths onto the DUTs.

The Tektronix AFG31101 is a high-performance arbitrary function generator (AFG) with built-in arbitrary waveform generation, real-time waveform monitoring, and the largest touchscreen on the market.

This product features basic and advanced modes making it suitable for a range of operators. In basic mode this unit can generate traditional functions and arbitary waveforms direct from the touchscreen interface. In advanced mode it is possible to sequence up to 256 waveforms and define the output sequence. Additionally advanced mode uses variable sample rate technology. Every sample in a waveform is output once and only once in each cycle, synchronised to the sample rate. Since there is no skipping or repetition, all details in the waveforms are kept. This feature is very useful for applications in which signal fidelity is extremely critical, such as IQ modulation and pulse train generation.

• Single channel 1µHz to 100MHz Sine frequency range.
• Patented InstaView™ technology enables engineers to see the actual waveform at the Device Under Test (DUT) in real time, without the need of an oscilloscope and probe, eliminating the uncertainty caused by mismatched impedance.
• Sequencing option adds the ability to program long, complex waveforms with up to 256 steps.
• The 9-inch capacitive touch screen works like a smart phone and has short-cuts to frequently used settings.
• Built-in ArbBuilder lets you create and edit arbitrary waveforms on the instrument, eliminating the need to connect to a PC.
• Outputs are protected from over voltage and current to minimize potential instrument damage.
• Built-in Double Pulse Test application to generate voltage pulses with varying pulse widths onto the DUTs.

The Tektronix AFG31102 is a high-performance arbitrary function generator (AFG) with built-in arbitrary waveform generation, real-time waveform monitoring, and the largest touchscreen on the market.

This product features basic and advanced modes making it suitable for a range of operators. In basic mode this unit can generate traditional functions and arbitary waveforms direct from the touchscreen interface. In advanced mode it is possible to sequence up to 256 waveforms and define the output sequence. Additionally advanced mode uses variable sample rate technology. Every sample in a waveform is output once and only once in each cycle, synchronised to the sample rate. Since there is no skipping or repetition, all details in the waveforms are kept. This feature is very useful for applications in which signal fidelity is extremely critical, such as IQ modulation and pulse train generation.

• Twin channel 1µHz to 100MHz Sine frequency range.
• Patented InstaView™ technology enables engineers to see the actual waveform at the Device Under Test (DUT) in real time, without the need of an oscilloscope and probe, eliminating the uncertainty caused by mismatched impedance.
• Sequencing option adds the ability to program long, complex waveforms with up to 256 steps.
• The 9-inch capacitive touch screen works like a smart phone and has short-cuts to frequently used settings.
• Built-in ArbBuilder lets you create and edit arbitrary waveforms on the instrument, eliminating the need to connect to a PC.
• Outputs are protected from over voltage and current to minimize potential instrument damage.
• Built-in Double Pulse Test application to generate voltage pulses with varying pulse widths onto the DUTs.

The Tektronix AFG31151 is a high-performance arbitrary function generator (AFG) with built-in arbitrary waveform generation, real-time waveform monitoring, and the largest touchscreen on the market.

This product features basic and advanced modes making it suitable for a range of operators. In basic mode this unit can generate traditional functions and arbitary waveforms direct from the touchscreen interface. In advanced mode it is possible to sequence up to 256 waveforms and define the output sequence. Additionally advanced mode uses variable sample rate technology. Every sample in a waveform is output once and only once in each cycle, synchronised to the sample rate. Since there is no skipping or repetition, all details in the waveforms are kept. This feature is very useful for applications in which signal fidelity is extremely critical, such as IQ modulation and pulse train generation.

• Single channel 1µHz to 150MHz Sine frequency range.
• Patented InstaView™ technology enables engineers to see the actual waveform at the Device Under Test (DUT) in real time, without the need of an oscilloscope and probe, eliminating the uncertainty caused by mismatched impedance.
• Sequencing option adds the ability to program long, complex waveforms with up to 256 steps.
• The 9-inch capacitive touch screen works like a smart phone and has short-cuts to frequently used settings.
• Built-in ArbBuilder lets you create and edit arbitrary waveforms on the instrument, eliminating the need to connect to a PC.
• Outputs are protected from over voltage and current to minimize potential instrument damage.
• Built-in Double Pulse Test application to generate voltage pulses with varying pulse widths onto the DUTs.

The Tektronix AFG31152 is a high-performance arbitrary function generator (AFG) with built-in arbitrary waveform generation, real-time waveform monitoring, and the largest touchscreen on the market.

This product features basic and advanced modes making it suitable for a range of operators. In basic mode this unit can generate traditional functions and arbitary waveforms direct from the touchscreen interface. In advanced mode it is possible to sequence up to 256 waveforms and define the output sequence. Additionally advanced mode uses variable sample rate technology. Every sample in a waveform is output once and only once in each cycle, synchronised to the sample rate. Since there is no skipping or repetition, all details in the waveforms are kept. This feature is very useful for applications in which signal fidelity is extremely critical, such as IQ modulation and pulse train generation.

• Twin channel 1µHz to 150MHz Sine frequency range.
• Patented InstaView™ technology enables engineers to see the actual waveform at the Device Under Test (DUT) in real time, without the need of an oscilloscope and probe, eliminating the uncertainty caused by mismatched impedance.
• Sequencing option adds the ability to program long, complex waveforms with up to 256 steps.
• The 9-inch capacitive touch screen works like a smart phone and has short-cuts to frequently used settings.
• Built-in ArbBuilder lets you create and edit arbitrary waveforms on the instrument, eliminating the need to connect to a PC.
• Outputs are protected from over voltage and current to minimize potential instrument damage.
• Built-in Double Pulse Test application to generate voltage pulses with varying pulse widths onto the DUTs.

The Tektronix AFG31251 is a high-performance arbitrary function generator (AFG) with built-in arbitrary waveform generation, real-time waveform monitoring, and the largest touchscreen on the market.

This product features basic and advanced modes making it suitable for a range of operators. In basic mode this unit can generate traditional functions and arbitary waveforms direct from the touchscreen interface. In advanced mode it is possible to sequence up to 256 waveforms and define the output sequence. Additionally advanced mode uses variable sample rate technology. Every sample in a waveform is output once and only once in each cycle, synchronised to the sample rate. Since there is no skipping or repetition, all details in the waveforms are kept. This feature is very useful for applications in which signal fidelity is extremely critical, such as IQ modulation and pulse train generation.

• Single channel 1µHz to 250MHz Sine frequency range.
• Patented InstaView™ technology enables engineers to see the actual waveform at the Device Under Test (DUT) in real time, without the need of an oscilloscope and probe, eliminating the uncertainty caused by mismatched impedance.
• Sequencing option adds the ability to program long, complex waveforms with up to 256 steps.
• The 9-inch capacitive touch screen works like a smart phone and has short-cuts to frequently used settings.
• Built-in ArbBuilder lets you create and edit arbitrary waveforms on the instrument, eliminating the need to connect to a PC.
• Outputs are protected from over voltage and current to minimize potential instrument damage.
• Built-in Double Pulse Test application to generate voltage pulses with varying pulse widths onto the DUTs.

The Tektronix AFG31252 is a high-performance arbitrary function generator (AFG) with built-in arbitrary waveform generation, real-time waveform monitoring, and the largest touchscreen on the market.

This product features basic and advanced modes making it suitable for a range of operators. In basic mode this unit can generate traditional functions and arbitary waveforms direct from the touchscreen interface. In advanced mode it is possible to sequence up to 256 waveforms and define the output sequence. Additionally advanced mode uses variable sample rate technology. Every sample in a waveform is output once and only once in each cycle, synchronised to the sample rate. Since there is no skipping or repetition, all details in the waveforms are kept. This feature is very useful for applications in which signal fidelity is extremely critical, such as IQ modulation and pulse train generation.

• Twin channel 1µHz to 250MHz Sine frequency range.
• Patented InstaView™ technology enables engineers to see the actual waveform at the Device Under Test (DUT) in real time, without the need of an oscilloscope and probe, eliminating the uncertainty caused by mismatched impedance.
• Sequencing option adds the ability to program long, complex waveforms with up to 256 steps.
• The 9-inch capacitive touch screen works like a smart phone and has short-cuts to frequently used settings.
• Built-in ArbBuilder lets you create and edit arbitrary waveforms on the instrument, eliminating the need to connect to a PC.
• Outputs are protected from over voltage and current to minimize potential instrument damage.
• Built-in Double Pulse Test application to generate voltage pulses with varying pulse widths onto the DUTs.

The FCA3003 Timer/Counter/Analyzer packs many different functions into one feature-rich instrument.

With industry-leading frequency and time resolution, the FCA3003 comes as standard with deep internal memory and a fast data transfer rate of 250k Samples/s to internal memory. In addition, the multi-parameter display shows auxiliary measurements alongside your main measurement to provide you with the results you need at a glance.

With the industry's most comprehensive analysis modes, including measurement statistics, histograms, and trend plots, you have the tools you need to quickly and accurately analyze your signal.

• Key Performance Specifications:
• 3GHz
• 300 to 400MHz in Manual Trigger Mode
• Up to 3 Input Channels
• 100ps Single-shot Time Resolution
• 12 Digit/s Frequency Resolution
• 0.001° Phase Resolution
• 3mV or better Voltage Resolution
• Optional 5 x 10^-8 High-stability Oven Time Base
• Measurement Throughput:
• 250k Sample/s Data Transfer Rate to Internal Memory (Up to 3.75M samples stored)
• Up to 15k Sample/s Data Transfer Rate over USB/GPIB Bus (Block mode)
• Up to 650 Individually Triggered Measurements/s
• Available Functions and Features:
• Automated Measurements: Frequency, Period, Ratio, Time Interval, Time Interval Error, Pulse Width, Rise/Fall Time, Phase Angle, Duty Cycle, Maximum Voltage, Minimum Voltage, Peak-to-Peak Voltage
• Multi-parameter Display
• Trend Plot Mode
• Measurement Statistics Mode
• Histogram Mode
• Allan Deviation
• Zero Dead-time Frequency/Period Measurements
• Programmable Pulse Output from 0.5Hz to 50MHz
• Connectivity:
• Optional Rear-panel Inputs
• USB Device and GPIB Ports on Rear Panel for Quick PC Connectivity
• GPIB Interface Supports Full SCPI-compatible Programmability and offers an Emulation Mode for Plug-and-Play Replacement in Existing ATE Systems
• External Arming Input
• 10MHz Reference Oscillator Output
• Includes National Instrument's LabVIEW SignalExpress™ TE Limited Edition Software for Connecting Your Bench
• Optional TimeView™ Software Available for Modulation Domain Analysis
• Tektronix 3-year Warranty

The Voltcraft DDS-3025 is a PC Function Generator that works in conjunction with a Windows® compatible computer with a USB interface. The DDS-3025 is a well equipped arbitrary DDS function generator with the additional advantage that the data can be stored and further processed.

The device has an output channel, and can produce arbitrary waveforms up to 25MHz and sine signals can be generated and output to 50MHz. The screen surface is modelled on a traditional function generator. The settings are made via the software.

The integrated pattern generator and frequency counter enable advanced analysis of digital systems. The power supply is via an optional USB power adaptor.

What's in the Box?Voltcraft DDS-3025USB cableBNC to BNC cableCD softwareUser's Guide

• 12-bit vertical resolution
• External trigger
• sync output
• Operation and setting via software
• Integration in LabView systems
• 4 digital inputs (6-bit) and 12 digital outputs (12 bits)
• Standalone function without a computer by internal memory
• ARB frequency range: 1Hz to 25MHz
• Channel type: 1
• Dimensions: 122(H) x 206(W) mm
• Distortion factor (sine): -50dBc
• Frequency range (sine): 1Hz to 50MHz
• Frequency range (square wave): 1Hz to 5MHz
• Frequency range (triangle): 1Hz to 10MHz
• Weight: 400g
• Manufacturer's part: Voltcraft DDS-3025

The Voltcraft FG 250D function generator is easy to use and reliable for applications in the NF-range up to 250kHz. The FG 250D is suitable for testing control circuits, analogue and digital circuits, or for measuring the frequency response of LF amplifiers, filters and speakers. The amplitude of sine and triangular signals can be modified in the range from 100mV to 5Vpp. The amplitude of the rectangular signal corresponds to the TTL-level (+5V). A DC-voltage coupled output (DC) opens up many usage possibilities in digital circuits through the continuous offset setting.

• Frequency range 1Hz to 250kHz in 1Hz steps
• Sine, triangle, rectangle (TTL) settings
• LCD display
• Dimensions 225 x 73 x 212mm
• Weighs 950g
