The Aim-TTi CPX200D replaces the best-selling CPX200, many thousands of which are in use across the world.

A wider PowerFlex range extends maximum voltage from 35V to 60V, whilst the maximum current of 10A is now available up to 16V rather than 12V.

Existing CPX200 owners will appreciate the new features of S-Lock, Range Control, Voltage Tracking and Synchronous On/Off. For those requiring bus control, the CPX200DP includes a full set of digital interfaces.

To meet the varying needs of today's engineers, a comprehensive array of interfaces is provided. RS-232, USB, GPIB and LAN (Ethernet) with LXI support are provided as standard. Each of the digital bus interfaces provides full control of voltage, current, and output on/off, plus read-back of voltage, current and status. The interfaces are at ground potential and are opto-isolated from the output terminals.

The GPIB interface is compliant with IEEE-488.1 and IEEE-488.2. Currently GPIB remains the most widely used interface for system applications.An RS-232/RS-423 interface is provided for use with legacy systems. This type of serial interface remains in common usage and is perfectly satisfactory for the control of power supplies because data speed is not an issue.

USB provides a simple and convenient means of connection to a PC and is particularly appropriate for small system use. A USB driver is provided which supports Windows 2000, XP , Vista and Windows 7.

The LAN interface uses a standard 10/100 base-T Ethernet hardware connection with ICMP and TCP/IP Protocol for connection to a Local Area Network or direct connection to a single PC. This interface supports LXI and is highly appropriate for system use because of its scalable nature and low cost interconnection.

The LAN interface is compliant with LXI-C. LXI (LAN eXtensions for Instrumentation) is the next-generation, LAN-based modular architecture standard for automated test systems managed by the LXI Consortium, and is expected to become the successor to GPIB in many systems.

• PowerFlex design gives variable voltage and current combinations within a maximum power envelope
• Up to 60V and up to 10A per output (180W maximum)
• Constant voltage or constant current operation
• Low output noise and good transient response
• PowerFlex or fixed-range operation plus custom limits
• True analogue controls with digital settings locking
• Independent outputs or isolated voltage tracking
• Outputs can be wired in series or parallel for 120V or 20A
• Variable OVP trips; safety binding-post terminals
• 4 digit fixed resolution meters; selectable remote sensing
• Compact ½ rack 3U case for bench use or rack mounting
• Duplicate terminals at rear on CPX200DP
• GPIB, RS-232, USB and LAN interfaces with LXI compliance (CPX200DP only)
• Manufacturer's part: Aim-TTi CPX200D

Not recommended for use as a battery charger.

The CPX200DP is a high performance autoranging dual 180W PowerFlex power supply, and is the bus programmable version of the standard CPX PSU. The unit has maximum ratings of 60V and 10A and can be operated in constant voltage or constant current modes. The PowerFlex design allows fixed-range operation or variable voltage and current combinations within a maximum power envelope. The USB, RS-232, GPIB and LSN interfaces provide the means for digital remote control. The PSU has dual 4-digit meters with 10mm easy to read characters and precise control is possible with the true analog controls with digital functionality. The S-Lock digitally locks voltage and current settings at the touch of a button. The power supply case is a compact ½ rack 3U case for bench and system use and the PSU is equally at home in the laboratory or workshop.

• Output 2x 180W 60V 10A
• Digital interfaces RS-232 USB LAN (LXI) GPIB
• Digital remote control and programming
• Easy series/parallel operation
• Dedicated button for both On or Off
• Low output noise and good transient response
• Selectable remote sensing
• Wide range voltage input
• Safety binding-post terminals
• Duplicate terminals at rear
• Supplied with driver software
• Overvoltage protection
• Overtemperature protection
• Safety interlocks

Not recommended for use as a battery charger.

The Aim-TTi CPX400D is a different type of laboratory power supply designed to meet the need for flexibility in the choice of voltage and current. A conventional PSU has a fixed current limit giving a power capability that reduces directly with the output voltage. The Aim-TTi CPX400D Power Flex design enables higher currents to be generated at lower voltages within an overall power limit envelope.Each output can provide considerably higher current than a conventional PSU of the same maximum voltage and power (see power curve). Example voltage and current combinations include 60V/7A, 42V/10A, 28V/15A, and 20V/20A.

As technology has changed, many products have moved from analog controls to digital ones. Although digital controls suit many instruments, they do not necessarily suit a bench power supply. Customer research shows that many users prefer the speed and simplicity of conventional analog controls for setting voltage and current. Digital controls may offer greater precision, but often at the expense of ease-of-use. With this in mind, the CPX400D retains the true analog controls of its predecessor. The main disadvantage of analog controls is stability and security. The settings of analog potentiometers can drift over time. More importantly, the settings can be changed accidentally with potentially serious consequences.

The Aim-TTi CPX400D incorporates S-Lock. One press of the lock button transfers control of voltage and current from the analog controls to internal digital circuitry. This offers not just complete security, but exceptional stability as well with each setting controlled by an instrumentation quality DAC.

• Dual isolated outputs, 420W each
• Power Flex design gives variable voltage and current combinations within a maximum power range
• Higher current capability at lower voltages
• Variable OVP trips
• Precision control and metering
• Selectable remote sense terminals
• Compact half-rack 3U case size
• Not recommended for use as a battery charger
• Manufacturer's part no. Aim-TTi CPX400D

The Aim-TTi Twin CPX400DP is a different type of laboratory power supply designed to meet the need for flexibility in the choice of voltage and current. A conventional PSU has a fixed current limit giving a power capability that reduces directly with the output voltage. The Aim-TTi Twin CPX400DP design enables higher currents to be generated at lower voltages within an overall power limit envelope.Each output can provide considerably higher current than a conventional PSU of the same maximum voltage and power (see power curve). Example voltage and current combinations include 60V/7A, 42V/10A, 28V/15A, and 20V/20A.

The PowerFlex regulation system used on the Aim-TTi Twin CPX400DP combines a high frequency pre regulator with a linear post regulator to give both low noise and good transient response. Each output can operate in constant voltage or constant current mode with automatic crossover and mode indication.

Separate voltage and current meters on each output give a resolution of 10mV and 10mA. The fixed resolution avoids the misinterpretation of readings that can occur with auto ranging 3 or 3½ digit meters where the decimal point position moves as the reading changes. Coarse and fine voltage controls are provided. The current control is logarithmic enabling low current levels to be set accurately. A View Settings button enables limit settings to be checked and adjusted at any time.

Each output incorporates remote sense terminals that can be enabled or disabled at the flick of a switch. Remote sensing is essential for maintaining precise regulation at the load and true metering of the load voltage.

• PowerFlex design gives variable voltage and current combinations within a maximum power envelope
• Up to 60V and up to 20A per output (420W maximum)
• Constant voltage or constant current operation
• Low output noise and good transient response
• PowerFlex or fixed-range operation plus custom limits
• True analogue controls with digital settings locking
• Independent outputs or isolated voltage tracking (dual)
• Outputs can be wired in series or parallel for 120V or 40A
• Variable OVP trips; safety binding-post terminals
• 4 digit fixed resolution meters; selectable remote sensing
• Compact ½ rack 3U case (dual) or ¼ rack 3U case (single)
• Duplicate terminals at rear
• GPIB, RS-232, USB and LAN interfaces with LXI class C compliance
• Manufacturers part no. Aim-TTi CPX400DP

Not recommended for use as a battery charger.

The Aim-TTi CPX400S is a new single output version of the best selling CPX400 series. The ultra-compact design (quarter rack 3U) takes up minimum space for bench or system use. PowerFlex regulation enables the 420W of power to be configured to suit each specific application.

The PowerFlex regulation system used on the Aim-TTi CPX400S combines a high frequency pre regulator with a linear post regulator to give both low noise and good transient response. Each output can operate in constant voltage or constant current mode with automatic crossover and mode indication.

Separate voltage and current meters on each output give a resolution of 10mV and 10mA. The fixed resolution avoids the misinterpretation of readings that can occur with auto-ranging 3 or 3½ digit meters where the decimal point position moves as the reading changes. Coarse and fine voltage controls are provided. The current control is logarithmic enabling low current levels to be set accurately. A view settings button enables limit settings to be checked and adjusted at any time.

Each output incorporates remote sense terminals that can be enabled or disabled at the flick of a switch. Remote sensing is essential for maintaining precise regulation at the load and true metering of the load voltage.

• PowerFlex design gives variable voltage and current combinations
• Up to 60V and up to 20A per output (420W maximum)
• Constant voltage or constant current operation
• Low output noise and good transient response
• PowerFlex or fixed-range operation plus custom limits
• True analogue controls with digital settings locking
• Outputs can be wired in series or parallel for 120V or 40A
• Variable OVP trips; safety binding-post terminals
• 4 digit fixed resolution meters; selectable remote sensing
• Compact ½ rack 3U case (dual) or ¼ rack 3U case (single)
• Isolated analogue control interface
• Manufacturers part no. Aim-TTi CPX400S

Not recommended for use as a battery charger.

The Aim-TTi Power Supply Single 420W PowerFlex CPX400SA is a different type of laboratory power supply designed to meet the need for flexibility in the choice of voltage and current.

A conventional PSU has a fixed current limit giving a power capability that reduces directly with the output voltage.

The design of the Aim-TTi PowerFlex CPX400SA enables higher currents to be generated at lower voltages within an overall power limit envelope. Each output can provide considerably higher current than a conventional PSU of the same maximum voltage and power (see power curve).Example voltage and current combinations include 60V/7A, 42V/10A, 28V/15A, and 20V/20A.

• PowerFlex design gives variable voltage and current combinations
• Up to 60V and up to 20A per output (420W maximum)
• Constant voltage or constant current operation
• Low output noise and good transient response
• PowerFlex or fixed-range operation plus custom limits
• True analogue controls with digital settings locking
• Independent outputs or isolated voltage tracking (dual)
• Outputs can be wired in series or parallel for 120V or 40A
• Variable OVP trips; safety binding-post terminals
• 4 digit fixed resolution meters; selectable remote sensing
• Compact ½ rack 3U case (dual) or ¼ rack 3U case (single)
• Isolated analogue control interface
• Manufacturers part no. Aim-TTi CPX400SA

Not recommended for use as a battery charger.

The CPX series is a different type of laboratory power supply designed to meet the need for flexibility in the choice of voltage and current. A conventional PSU has a fixed current limit giving a power capability that reduces directly with the output voltage. The TTi PowerFlex design of the CPX series enables higher currents to be generated at lower voltages within an overall power limit envelope.

Each output can provide considerably higher current than a conventional PSU of the same maximum voltage and power. The two outputs of the CPX400D are completely independent and electrically isolated from each other. With V-Track selected, the two outputs remain electrically isolated, but the voltage control of the Master output sets an identical voltage on the Slave output.

This enables the user to create two rails of either polarity and to reference them to different grounds if necessary (e.g. digital ground and analog ground). Alternatively the outputs can be wired in series or parallel to create a voltage capability up to 120V or a current capability up to 40A with the voltage set using a single control.

• PowerFlex design gives variable voltage and current
• combinations within a maximum power envelope
• Up to 60V and up to 20A per output (420W maximum)
• Constant voltage or constant current operation
• Low output noise and good transient response
• PowerFlex or fixed-range operation plus custom limits
• True analogue controls with digital settings locking
• Independent outputs or isolated voltage tracking (dual)
• Outputs can be wired in series or parallel for 120V or 40A
• Variable OVP trips; safety binding-post terminals
• 4 digit fixed resolution meters; selectable remote sensing
• Compact ½ rack 3U case (dual) or ¼ rack 3U case (single)
• Duplicate terminals at rear
• GPIB, RS-232, USB and LAN interfaces with LXI class C compliance
• Manufacturers part no. Aim-TTi CPX400SP

Not recommended for use as a battery charger.

This single output PSU from the Aim-TTi EL series has been designed to meet the need for a compact power supply that provides good performance at a low price.

• Power rating 75W
• Output current 5A
• Voltage 0 to 15V
• Compact design takes up minimal bench space
• Linear regulation
• Quiet operation
• Excellent line and load regulation
• Low noise
• Good transient response
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Seperate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and protected against external voltages and reverse currents
• Complies with EN61010-1 and EN61326

This single output PSU from the Aim-TTi EL series has been designed to meet the need for a compact power supply that provides good performance at a low price.

• Power rating 60W
• Output current 3.3A
• Voltage 0 to 18V
• Compact design takes up minimal bench space
• Linear regulation
• Quiet operation
• Excellent line and load regulation
• Low noise
• Good transient response
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Seperate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and protected against external voltages and reverse currents
• Complies with EN61010-1 and EN61326

This single output PSU from the Aim-TTi EL series has been designed to meet the need for a compact power supply that provides good performance at a low price.

• Power rating 30W
• Output current 1A
• Voltage 0 to 30V
• Compact design takes up minimal bench space
• Linear regulation
• Quiet operation
• Excellent line and load regulation
• Low noise
• Good transient response
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Seperate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and protected against external voltages and reverse currents
• Complies with EN61010-1 and EN61326

This single output PSU from the Aim-TTi EL series has been designed to meet the need for a compact power supply that provides good performance at a low price.

• Power rating 60W
• Output current 2A
• Voltage 0 to 30V
• Compact design takes up minimal bench space
• Linear regulation
• Quiet operation
• Excellent line and load regulation
• Low noise
• Good transient response
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Seperate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and protected against external voltages and reverse currents
• Complies with EN61010-1 and EN61326
• Features an RS-232 interface to give a basic programmable PSU

This single output PSU from the Aim-TTi EL series has been designed to meet the need for a compact power supply that provides good performance at a low price.

• Power rating 60W
• Output current 2A
• Voltage 0 to 30V
• Compact design takes up minimal bench space
• Linear regulation
• Quiet operation
• Excellent line and load regulation
• Low noise
• Good transient response
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Seperate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and protected against external voltages and reverse currents
• Complies with EN61010-1 and EN61326

The Aim-TTi EL302RT has been developed from the top selling EL series. By adding four digit meters and switchable remote sensing, the Thurlby Thandar EL302RT offers much higher precision whilst retaining the simplicity of operation which many bench-top power supply users prefer.

The Aim-TTi EL302RT uses true linear regulation for the best possible performance. Excellent line and load regulation is matched by very low output noise and good transient response.

It also incorporates separate voltage and current meters on each main output with a resolution of 10mV and 1mA. The fixed resolution avoids the misinterpretation of readings that can occur with auto-ranging 3 or 3½ digit meters where the decimal point position moves as the reading changes.

Each main output of the Thurlby Thandear EL302RT has a DC on-off switch. This enables voltage and current settings to be viewed before the load is connected and allows multiple outputs to be controlled individually. Surprisingly, many power supplies omit this essential feature.The Aim-TTi EL302RT uses classic analog controls for voltage and current. The large and bright displays have a fixed resolution to avoid confusion. Preset voltage and current levels are shown when the DC output switch is turned off. Remote sense is available when needed but is disabled by setting the switch to local.

• Single outputs, 30V/1A, 18V/3.3A, 56V/1.1A, 15V/5A, 30V/3A
• Single, dual or triple outputs, 30V/2A
• Independent digital voltage and current meters for each output with 4 digit resolution
• Switchable local or remote sensing
• Constant voltage or constant current operation
• Variable 1.5 to 5.0V auxiliary output at 2A (EL302RT)
• Compact design uses less bench space
• Silent fan-free cooling
• DC output switches, automatic mode indication
• Manufacturer's part no. Aim-TTi EL302RT

Not recommended for use as a battery charger.

This single output PSU from the Aim-TTi EL series has been designed to meet the need for a compact power supply that provides good performance at a low price.

• Power rating 90W
• Output current 3A
• Voltage 0 to 30V
• Compact design takes up minimal bench space
• Linear regulation
• Quiet operation
• Excellent line and load regulation
• Low noise
• Good transient response
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Seperate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and protected against external voltages and reverse currents
• Complies with EN61010-1 and EN61326

This single output PSU from the Aim-TTi EL series has been designed to meet the need for a compact power supply that provides good performance at a low price.

• Power rating 60W
• Output current 1.1A
• Voltage 0 to 56V
• Compact design takes up minimal bench space
• Linear regulation
• Quiet operation
• Excellent line and load regulation
• Low noise
• Good transient response
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Seperate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and protected against external voltages and reverse currents
• Complies with EN61010-1 and EN61326

This high power compact single output switch mode PSU from the Aim-TTi EX series provides a high level of power at a very affordable price. By combining switch-mode pre-regulation with linear post-regulation, performance levels comparable to an all linear design have been achieved.

• Power 180W
• Output current 10A
• Output voltage 18V
• Compact design takes up minimal bench space
• Quiet operation
• Mixed-mode regulation
• Excellent line and load regulation
• Low noise
• Good transient response
• High power efficiency
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Separate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and fully protected against external voltages and reverse currents
• Remote sensing
• Complies with EN61010-1 and EN61326

Not recommended for use as a battery charger.

This high power compact single output switch mode PSU from the Aim-TTi EX series provides a high level of power at a very affordable price. By combining switch-mode pre-regulation with linear post-regulation, performance levels comparable to an all linear design have been achieved.

• Power 400W
• Output current 20A
• Output voltage 20V
• Compact design takes up minimal bench space
• Quiet operation
• Mixed-mode regulation
• Excellent line and load regulation
• Low noise
• Good transient response
• High power efficiency
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Separate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and fully protected against external voltages and reverse currents
• Remote sensing
• Complies with EN61010-1 and EN61326

Not recommended for use as a battery charger.

This high power compact dual output switch mode PSU from the Aim-TTi EX series provides a high level of power at a very affordable price. By combining switch-mode pre-regulation with linear post-regulation, performance levels comparable to an all linear design have been achieved.

• Power 280W
• Output current 2 x 4A
• Output voltage 2 x 35V
• Compact design takes up minimal bench space
• Quiet operation
• Mixed-mode regulation
• Excellent line and load regulation
• Low noise
• Good transient response
• High power efficiency
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Separate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and fully protected against external voltages and reverse currents
• Remote sensing
• Complies with EN61010-1 and EN61326

Not recommended for use as a battery charger.

This high power compact triple output switch mode PSU from the Aim-TTi EX series provides a high level of power at a very affordable price. By combining switch-mode pre-regulation with linear post-regulation, performance levels comparable to an all linear design have been achieved.

• Power 305W
• Output current 5A, 4A and 5A
• Output voltage 2 x 35V and 1.5 to 5V
• Compact design takes up minimal bench space
• Quiet operation
• Mixed-mode regulation
• Excellent line and load regulation
• Low noise
• Good transient response
• High power efficiency
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Separate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and fully protected against external voltages and reverse currents
• Remote sensing
• Complies with EN61010-1 and EN61326

Not recommended for use as a battery charger.

This high power compact single output switch mode PSU from the Aim-TTi EX series provides a high level of power at a very affordable price. By combining switch-mode pre-regulation with linear post-regulation, performance levels comparable to an all linear design have been achieved.

• Power 175W
• Output current 5A
• Output voltage 35V
• Compact design takes up minimal bench space
• Quiet operation
• Mixed-mode regulation
• Excellent line and load regulation
• Low noise
• Good transient response
• High power efficiency
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Separate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and fully protected against external voltages and reverse currents
• Complies with EN61010-1 and EN61326
• Features an RS-232 interface to give a basic programmable PSU

Not recommended for use as a battery charger.

This high power compact single output switch mode PSU from the Aim-TTi EX series provides a high level of power at a very affordable price. By combining switch-mode pre-regulation with linear post-regulation, performance levels comparable to an all linear design have been achieved.

• Power 175W
• Output current 5A
• Output voltage 35V
• Compact design takes up minimal bench space
• Quiet operation
• Mixed-mode regulation
• Excellent line and load regulation
• Low noise
• Good transient response
• High power efficiency
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Separate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and fully protected against external voltages and reverse currents
• Remote sensing
• Complies with EN61010-1 and EN61326

Not recommended for use as a battery charger.

This high power compact single output switch mode PSU from the Aim-TTi EX series provides a high level of power at a very affordable price. By combining switch-mode pre-regulation with linear post-regulation, performance levels comparable to an all linear design have been achieved.

• Power 420W
• Output current 10A
• Output voltage 42V
• Compact design takes up minimal bench space
• Quiet operation
• Mixed-mode regulation
• Excellent line and load regulation
• Low noise
• Good transient response
• High power efficiency
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Separate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and fully protected against external voltages and reverse currents
• Remote sensing
• Complies with EN61010-1 and EN61326

Not recommended for use as a battery charger.

This high power compact dual output switch mode PSU from the Aim-TTi EX series provides a high level of power at a very affordable price. By combining switch-mode pre-regulation with linear post-regulation, performance levels comparable to an all linear design have been achieved.

• Power 300W
• Output current 2A and 4A
• Output voltage 2 x 75V
• Compact design takes up minimal bench space
• Quiet operation
• Mixed-mode regulation
• Excellent line and load regulation
• Low noise
• Good transient response
• High power efficiency
• Constant voltage and constant current modes with automatic crossover
• Coarse and fine voltage control
• Logarithmic current control enabling low currents to be accurately set
• Separate digital voltmeter and ammeter for each main output
• Current limit settings are displayed when output switch is off, enabling verification of settings
• Bright LED display with 14mm high characters and an update rate of four per second
• All outputs short circuit proof and fully protected against external voltages and reverse currents
• Remote sensing
• Complies with EN61010-1 and EN61326

Not recommended for use as a battery charger.

This 315W versatile, high performance triple output DC power supply has the features and performance that make it ideal for professional use in the laboratory, workshop, classroom, etc. The three fully functional outputs have fully variable voltage and current and can operate in constant voltage or constant current modes. Each output is supported by simultaneous high resolution LCD metering, switchable remote sensing, and individual or combined output On/Off with programmable sequencing. To give the PSU more flexibility for different applications, each output is multirange to give the choice of higher voltage or higher current. For tasks where higher power is required, two of the outputs may be combined internally to provide twice the power from a single output. The PSU has intuitive, easy to use controls and clear readouts, making it easy to operate. There are comprehensive setting memories, with 50x per output plus 50 linked memories and all outputs have variable OCP and OVP trips.

• Three full performance output
• Multiple voltage/current ranges
• High resolution LCD meters
• Selectable voltage tracking
• Numeric or spin-wheel control
• 3U ½ Rack case for bench or rack mounting
• Low output noise and ripple
• Model no. MX100T

Not recommended for use as a battery charger.

This 315W versatile, high performance triple output DC power supply has the features and performance that make it ideal for professional use in the laboratory, workshop, classroom, etc. The three fully functional outputs have fully variable voltage and current and can operate in constant voltage or constant current modes. Each output is supported by simultaneous high resolution LCD metering, switchable remote sensing, and individual or combined output On/Off with programmable sequencing. To give the PSU more flexibility for different applications, each output is multirange to give the choice of higher voltage or higher current. For tasks where higher power is required, two of the outputs may be combined internally to provide twice the power from a single output. The PSU has intuitive, easy to use controls and clear readouts, making it easy to operate. There are comprehensive setting memories, with 50x per output plus 50 linked memories and all outputs have variable OCP and OVP trips. This model features USB, RS-232, GPIB, and LAN (LXI) digital bus interfaces that provide full control of voltage, current, output On/Off and set-up, as well as read-back of voltage, current and status. All digital interfaces are optoisolated from the power output and are at earth potential.

• Three full performance output
• Multiple voltage/current ranges
• High resolution LCD meters
• Selectable voltage tracking
• Numeric or spin-wheel control
• 3U ½ Rack case for bench or rack mounting
• Low output noise and ripple
• Model no. MX100TP

Not recommended for use as a battery charger.

This 375W versatile, high performance triple output DC power supply has the features and performance that make it ideal for professional use in the laboratory, workshop, classroom, etc. The three fully functional outputs have fully variable voltage and current and can operate in constant voltage or constant current modes. Each output is supported by simultaneous high resolution LCD metering, switchable remote sensing, and individual or combined output On/Off with programmable sequencing. To give the PSU more flexibility for different applications, each output is multirange to give the choice of higher voltage or higher current. For tasks where higher power is required, two of the outputs may be combined internally to provide twice the power from a single output. The PSU has intuitive, easy to use controls and clear readouts, making it easy to operate. There are comprehensive setting memories, with 50x per output plus 50 linked memories and all outputs have variable OCP and OVP trips.

• Three full performance output
• Multiple voltage/current ranges
• High resolution LCD meters
• Selectable voltage tracking
• Numeric or spin-wheel control
• 3U ½ Rack case for bench or rack mounting
• Low output noise and ripple
• Model no. MX180T

Not recommended for use as a battery charger.

This 375W versatile, high performance triple output DC power supply has the features and performance that make it ideal for professional use in the laboratory, workshop, classroom, etc. The three fully functional outputs have fully variable voltage and current and can operate in constant voltage or constant current modes. Each output is supported by simultaneous high resolution LCD metering, switchable remote sensing, and individual or combined output On/Off with programmable sequencing. To give the PSU more flexibility for different applications, each output is multirange to give the choice of higher voltage or higher current. For tasks where higher power is required, two of the outputs may be combined internally to provide twice the power from a single output. The PSU has intuitive, easy to use controls and clear readouts, making it easy to operate. There are comprehensive setting memories, with 50x per output plus 50 linked memories and all outputs have variable OCP and OVP trips. This model features USB, RS-232, GPIB, and LAN (LXI) digital bus interfaces that provide full control of voltage, current, output On/Off and set-up, as well as read-back of voltage, current and status. All digital interfaces are optoisolated from the power output and are at earth potential.

• Three full performance output
• Multiple voltage/current ranges
• High resolution LCD meters
• Selectable voltage tracking
• Numeric or spin-wheel control
• 3U ½ Rack case for bench or rack mounting
• Low output noise and ripple
• Model no. MX180TP

Not recommended for use as a battery charger.

Over the years, the PL series has been steadily revised and extended. Hundreds of thousands of PL series units are currently in use across the world and it remains the laboratory power supply of choice for many organisations.

The Aim-TTi Single PL155 achieves an exceptional power density for a linear regulated power supply by offering up to 90W from a ¼ rack 3U sized casing.

This gives it an unusually small bench footprint taking up less space on a crowded bench. For rack-mount application, up to four units can be mounted into a single slot. Despite its small size and linear regulation, the Aim-TTi Single PL155 generates relatively little heat through the use of an advanced phase controlled pre-regulator.

This gives it significantly higher energy efficiency than conventional linear regulated designs, particularly when supplying lower voltages.The internal heat-sinks use fan-assisted convection cooling in order to remove the heat with minimal fan noise.

• Single output or dual output models
• Linear regulation - for the best performance
• Ultra-compact design - uses up less space
• True Analog controls - for ease of use
• S-Lock function - instantly lock settings
• V-Span function - customise the voltage range
• Low current range and current meter averaging
• DC output switches and view limits button
• Selectable remote sense terminals
• Independent, Isolated Tracking, Ratio Tracking and True Parallel modes on dual output model
• Manufacturers part no. Aim-TTi EB2025T

Not recommended for use as a battery charger.

The Aim-TTi PL155-P offers remote control and read-back using analog, RS232, USB, LAN (LXI) interfaces. They retain all of the capabilities of the New PL Series when under manual control.

When working with any particular piece of equipment, engineers often require a voltage source variable over only a narrow range. Set the voltage too high and damage might occur, set it too low and the circuit may reset.

That’s where the V-Span function of the New PL series comes in. It allows the user to redefine the end-stop values of the voltage control to define a specific voltage range.

An engineer is working on a circuit that will eventually operate from four NiMh cells. They use V-Span to set a Vmax of 5.8V (to prevent over-voltage damage) and a Vmin of 3.6V (to ensure that the circuit doesn’t reset). They now have a power supply which provides high resolution analog control over the exact voltage range they need.

• High performance linear regulated power supplies
• Full digital remote control and read back
• RS-232, USB and LAN (Ethernet), GPIB optional
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density - up to 90W per output
• Manufacturers part no. Aim-TTi PL155-P

Not recommended for use as a battery charger.

The Aim-TTi PL155-P (G) offers remote control and read-back using analog, RS232, USB, LAN (LXI) interfaces. They retain all of the capabilities of the New PL Series when under manual control. This version is supplied with the GPIB interface.

When working with any particular piece of equipment, engineers often require a voltage source variable over only a narrow range. Set the voltage too high and damage might occur, set it too low and the circuit may reset.

That’s where the V-Span function of the Aim-TTi PL155-P (G)  comes in. It allows the user to redefine the end-stop values of the voltage control to define a specific voltage range.

An engineer is working on a circuit that will eventually operate from four NiMh cells. They use V-Span to set a Vmax of 5.8V (to prevent over-voltage damage) and a Vmin of 3.6V (to ensure that the circuit doesn’t reset). They now have a power supply which provides high resolution analog control over the exact voltage range they need.

• High performance linear regulated power supplies
• Full digital remote control and read back
• RS-232, USB and LAN (Ethernet),
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density - up to 90W per output
• Manufacturers part no. Aim-TTi PL155-P (G) GPIB

Not recommended for use as a battery charger.

A 0 to 30V, 0 to 3A power supply from Aim-TTi's PL series.

The PL series achieves an exceptional power density for a linear regulated power supply by offering up to 90 watts from a ¼ rack 3U sized casing. This gives it an unusually small bench footprint taking up less space on a crowded bench.

Despite its small size and linear regulation, the New PL series generates relatively little heat through the use of an advanced phase controlled pre-regulator. This gives it significantly higher energy efficiency than conventional linear regulated designs, particularly when supplying lower voltages. The internal heat-sinks use fan-assisted convection cooling in order to remove the heat with minimal fan noise.

• High performance linear regulated power supply
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density, up to 90W per output
• Manual control features as per New PL Series
• Manufacturers part no. Aim-TTi PL303

Not recommended for use as a battery charger.

The Aim-TTi PL303-P offers remote control and read-back using analog, RS232, USB, LAN (LXI) interfaces. They retain all of the capabilities of the New PL Series when under manual control.

When working with any particular piece of equipment, engineers often require a voltage source variable over only a narrow range. Set the voltage too high and damage might occur, set it too low and the circuit may reset.

That’s where the V-Span function of the Aim-TTi PL303-P comes in. It allows the user to redefine the end-stop values of the voltage control to define a specific voltage range.

An engineer is working on a circuit that will eventually operate from four NiMh cells. They use V-Span to set a Vmax of 5.8V (to prevent over-voltage damage) and a Vmin of 3.6V (to ensure that the circuit doesn’t reset). They now have a power supply which provides high resolution analog control over the exact voltage range they need.

• High performance linear regulated power supplies
• Full digital remote control and read back
• RS-232, USB and LAN (Ethernet), GPIB optional
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density - up to 90W per output
• Manufacturers part no. Aim-TTi PL303-P

Not recommended for use as a battery charger.

The Aim-TTi PL303-P(G) offers remote control and read-back using analog, RS232, USB, LAN (LXI) interfaces. They retain all of the capabilities of the New PL Series when under manual control. This version is supplied with the GPIB interface.

When working with any particular piece of equipment, engineers often require a voltage source variable over only a narrow range. Set the voltage too high and damage might occur, set it too low and the circuit may reset.

That’s where the V-Span function of the Aim-TTi PL303-P(G) comes in. It allows the user to redefine the end-stop values of the voltage control to define a specific voltage range.

An engineer is working on a circuit that will eventually operate from four NiMh cells. They use V-Span to set a Vmax of 5.8V (to prevent over-voltage damage) and a Vmin of 3.6V (to ensure that the circuit doesn’t reset). They now have a power supply which provides high resolution analog control over the exact voltage range they need.

• High performance linear regulated power supplies
• Full digital remote control and read back
• RS-232, USB and LAN (Ethernet)
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density - up to 90W per output
• Manufacturers part no. Aim-TTi PL303-P (G) GPIB

Not recommended for use as a battery charger.

The Aim-TTi PL303QMD-P achieves an exceptional power density for a linear regulated power supply by offering up to 90W from a ¼ rack 3U sized casing. This gives it an unusually small bench footprint taking up less space on a crowded bench. For rack-mount application, up to four units can be mounted into a single slot.

Despite its small size and linear regulation, the Aim-TTi PL601-P generates relatively little heat through the use of an advanced phase controlled pre-regulator. This gives it significantly higher energy efficiency than conventional linear regulated designs, particularly when supplying lower voltages.

The internal heat-sinks use fan-assisted convection cooling in order to remove the heat with minimal fan noise.

To meet the varying needs of todays engineers, the Aim-TTi PL303QMD-P has a comprehensive array of interfaces is provided. RS-232, USB and LAN (Ethernet) with LXI support are provided as standard. An additional GPIB interface is also optionally available.

Each of the digital bus interfaces provides full control of voltage, current, and output on/off, plus read-back of voltage, current and status. The interfaces are at ground potential and are opto-isolated from the output terminals.

• High performance linear regulated power supplies
• Full digital remote control and readback
• RS-232, USB and LAN (Ethernet), GPIB optional
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density - up to 90W per output
• Manual control features as per New PL Series
• Manufacturers part no. Aim-TTi PL303QMD-P

Not recommended for use as a battery charger.

¼ rack 3U sized casing. This gives it an unusually small bench footprint taking up less space on a crowded bench. For rack-mount application, up to four units can be mounted into a single slot.

Despite its small size and linear regulation, the Aim-TTi PL601-P(G) generates relatively little heat through the use of an advanced phase controlled pre-regulator. This gives it significantly higher energy efficiency than conventional linear regulated designs, particularly when supplying lower voltages. This version is supplied with the GPIB interface.

The internal heat-sinks use fan-assisted convection cooling in order to remove the heat with minimal fan noise.

To meet the varying needs of todays engineers, the Aim-TTi PL303QMD-P(G) has a comprehensive array of interfaces is provided. RS-232, USB and LAN (Ethernet) with LXI and GPIB support are provided as standard.

Each of the digital bus interfaces provides full control of voltage, current, and output on/off, plus read-back of voltage, current and status. The interfaces are at ground potential and are opto-isolated from the output terminals.

• High performance linear regulated power supplies
• Full digital remote control and readback
• RS-232, USB and LAN (Ethernet)
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density - up to 90W per output
• Manual control features as per New PL Series
• Manufacturers part no. Aim-TTi PL303QMD-P(G) GPIB

Not recommended for use as a battery charger.

The Aim-TTi Single PL601 achieves an exceptional power density for a linear regulated power supply by offering up to 90 watts from a ¼ rack 3U sized casing. This gives it an unusually small bench footprint taking up less space on a crowded bench. For rack-mount application, up to four units can be mounted into a single slot.

Despite its small size and linear regulation, the New PL series generates relatively little heat through the use of an advanced phase controlled pre-regulator. This gives it significantly higher energy efficiency than conventional linear regulated designs, particularly when supplying lower voltages. The internal heat-sinks use fan-assisted convection cooling in order to remove the heat with minimal fan noise.

• High performance linear regulated power supplies
• Full digital remote control and read back
• RS-232, USB and LAN (Ethernet), GPIB optional
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density - up to 90W per output
• Manual control features as per New PL Series
• Manufacturers part no. Aim-TTi PL601

Not recommended for use as a battery charger.

The Aim-TTi PL601-P achieves an exceptional power density for a linear regulated power supply by offering up to 90W from a ¼ rack 3U sized casing. This gives it an unusually small bench footprint taking up less space on a crowded bench. For rack-mount application, up to four units can be mounted into a single slot.

Despite its small size and linear regulation, the Aim-TTi PL601-P generates relatively little heat through the use of an advanced phase controlled pre-regulator. This gives it significantly higher energy efficiency than conventional linear regulated designs, particularly when supplying lower voltages.

The internal heat-sinks use fan-assisted convection cooling in order to remove the heat with minimal fan noise.

To meet the varying needs of todays engineers, the Aim-TTi PL601-P has a comprehensive array of interfaces is provided. RS-232, USB and LAN (Ethernet) with LXI support are provided as standard. An additional GPIB interface is also optionally available.

Each of the digital bus interfaces provides full control of voltage, current, and output on/off, plus read-back of voltage, current and status. The interfaces are at ground potential and are opto-isolated from the output terminals.

• High performance linear regulated power supplies
• Full digital remote control and readback
• RS-232, USB and LAN (Ethernet), GPIB optional
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density - up to 90W per output
• Manual control features as per New PL Series
• Manufacturers part no. Aim-TTi PL601-P

Not recommended for use as a battery charger.

The Aim-TTi PL601-P(G) achieves an exceptional power density for a linear regulated power supply by offering up to 90W from a ¼ rack 3U sized casing. This gives it an unusually small bench footprint taking up less space on a crowded bench. For rack-mount application, up to four units can be mounted into a single slot. This version is supplied with the GPIB interface.

Despite its small size and linear regulation, the Aim-TTi PL601-P(G) generates relatively little heat through the use of an advanced phase controlled pre-regulator. This gives it significantly higher energy efficiency than conventional linear regulated designs, particularly when supplying lower voltages.

The internal heat-sinks use fan-assisted convection cooling in order to remove the heat with minimal fan noise.

To meet the varying needs of todays engineers, the Aim-TTi PL601-P(G) has a comprehensive array of interfaces is provided. RS-232, USB and LAN (Ethernet) with LXI and GPIB support are provided as standard.

Each of the digital bus interfaces provides full control of voltage, current, and output on/off, plus read-back of voltage, current and status. The interfaces are at ground potential and are opto-isolated from the output terminals.

• High performance linear regulated power supplies
• Full digital remote control and readback
• RS-232, USB and LAN (Ethernet)
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density - up to 90W per output
• Manual control features as per New PL Series
• Manufacturers part no. Aim-TTi PL601-P(G) GPIB

Not recommended for use as a battery charger.

The technology leader Aim-TTi is one of the world’s major producers of laboratory power supplies (PSUs). Aim-TTi has been a major technology innovator in PSUs since 1979 and now offers products ranging from 15W up to 1200W. Hundreds of thousands of Aim-TTi power supplies are in everyday use around the world.

The Aim-TTi PLH120 is a development of the best-selling New PL series of laboratory bench power supplies which is available in 15V, 30V and 60V variants (covered in a separate brochure and on our web site). The Thurlby Thandar Single PLH120 retains the ultra compact format, high power density, and smart analog controls of the PL series but offers voltages up to 250V to cover applications beyond the capabilities of standard bench PSUs and into areas such as magnetics. The Aim-TTi Single PLH120 has been at the forefront of laboratory power supply design for around thirty years during which it has re-defined the state-of-the-art for switch mode products with its innovative Mixed-mode and Power Flex regulator designs.

Demand for linear regulated PSUs has remained strong and continuing development of linear models has generated the lower cost ELR series, and the advanced QL series in addition to the ever popular PL series.

• Linear regulation provides ultra-low noise
• Highly compact (¼ rack 3U) with small bench footprint
• True analog controls with advanced digital features
• Settings can be locked at the touch of a button
• 4 digit voltage and current meters on each output
• Low current range with 0.1mA resolution
• Constant voltage or constant current operation
• Independent, tracking or true parallel modes (PL303QMD)
• Front and rear power and sense terminals (PL-P models)
• Analog remote control (PL-P single output models)
• RS-232, USB and LAN/LXI interfaces (PL-P model)s
• Manufacturers part no. Aim-TTi PLH120

Not recommended for use as a battery charger.

The Aim-TTi PLH120-P retains the ultra compact format, high power density, and smart analog controls of the PLH120-P, but offers voltages up to 120V to cover applications beyond the capabilities of standard bench PSUs and into areas such as magnetics.

As technology has changed, many products have moved from analog controls to digital ones. Although digital controls suit many instruments, they do not necessarily suit a bench power supply. Customer research shows that many users prefer the speed and simplicity of conventional analog controls for setting voltage and current. Digital controls may offer greater precision, but often at the expense of ease of use. With this in mind, the Aim-TTi PLH120-P has retained the true analog controls of its best selling sister products, the PL series.

The main disadvantage of analog controls is stability and security. The settings of analog potentiometers can drift over time. More importantly, the settings can be changed accidentally with potentially serious consequences. The Aim-TTi PLH120-P incorporates S-Lock. One press of the Lock button transfers control of voltage and current from the analog controls to internal digital circuitry. This offers not just complete security, but exceptional stability as well with each setting controlled by an instrumentation quality DAC.

• High performance linear regulated power supplies
• Full digital remote control and read back
• RS-232, USB and LAN (Ethernet), GPIB optional
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Isolated Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density, up to 94W per output
• Manual control features as per PLH Series
• Manufacturer's part no. Aim-TTi PLH120-P

Not recommended for use as a battery charger.

The Aim-TTi PLH120-P (G) retains the ultra compact format, high power density, and smart analog controls of the PLH120-P (G), but offers voltages up to 120V to cover applications beyond the capabilities of standard bench PSUs and into areas such as magnetics. This particular model is fitted with GPIB (option G) being an (IEEE-488) interface in addition to USB, RS232 and LAN.

The Aim-TTi PLH120-P (G) achieves an exceptional power density for a linear regulated power supply by offering up to 94W from a ¼ rack 3U sized casing. This gives it an unusually small bench footprint taking up less space on a crowded bench. For rack-mount application, up to four units can be mounted into a single slot. Despite its small size and linear regulation, the Thurlby Thandar PLH120-P (G) generates relatively little heat through the use of an advanced phase controlled pre-regulator. This gives it significantly higher energy efficiency than conventional linear regulated designs, particularly when supplying voltages below maximum.

The internal heat-sinks use fan-assisted convection cooling in order to remove the heat with minimal fan noise.

The Aim-TTi PLH120-P (G) includes all of the manual control features of the PLH series, but adds comprehensive remote control facilities. The ultra-compact rack-modular sizing makes it ideally suited to rack mounted system applications, while its user-friendly manual controls are retained for bench top applications. Power output terminals are duplicated on the rear panel for rack mount applications or other situations where rear connection is more appropriate.

• High performance linear regulated power supplies
• Full digital remote control and read back
• RS-232, USB and LAN (Ethernet), GPIB optional
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Isolated Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density, up to 94W per output
• Manual control features as per PLH Series
• Manufacturer's part no. Aim-TTi PLH120-P (G)

Not recommended for use as a battery charger.

The Aim-TTi PLH250 retains the ultra compact format, high power density, and smart analog controls of the PL series but offers voltages up to 250V to cover applications beyond the capabilities of standard bench PSUs and into areas such as magnetics.

As technology has changed, many products have moved from analog controls to digital ones. Although digital controls suit many instruments, they do not necessarily suit a bench power supply. Customer research shows that many users prefer the speed and simplicity of conventional analog controls for setting voltage and current. Digital controls may offer greater precision, but often at the expense of ease of use. With this in mind, the Aim-TTi PLH250 has retained the true analog controls of its best selling sister products, the PL series.

The main disadvantage of analog controls is stability and security. The settings of analog potentiometers can drift over time. More importantly, the settings can be changed accidentally with potentially serious consequences. The Thurlby Thander PLH250 incorporates S-Lock. One press of the Lock button transfers control of voltage and current from the analog controls to internal digital circuitry. This offers not just complete security, but exceptional stability as well with each setting controlled by an instrumentation quality DAC.

• Single output 120V 90W or 250V 94W
• Linear regulation - for the best performance
• Ultra-compact design - uses up less space
• True Analog controls - for ease of use
• S-Lock function instantly lock settings
• V-Span function customise the voltage range
• Low current range and current meter averaging
• DC output switches and view limits button
• Selectable remote sense terminals
• Manufacturer's part no. Aim-TTi PLH250

Not recommended for use as a battery charger.

The Aim-TTi PLH250-P retains the ultra compact format, high power density, and smart analog controls of the PLH250-P, but offers voltages up to 250V to cover applications beyond the capabilities of standard bench PSUs and into areas such as magnetics.

As technology has changed, many products have moved from analog controls to digital ones. Although digital controls suit many instruments, they do not necessarily suit a bench power supply. Customer research shows that many users prefer the speed and simplicity of conventional analog controls for setting voltage and current. Digital controls may offer greater precision, but often at the expense of ease of use. With this in mind, the Aim-TTi PLH250-P has retained the true analog controls of its best selling sister products, the PL series.

The main disadvantage of analog controls is stability and security. The settings of analog potentiometers can drift over time. More importantly, the settings can be changed accidentally with potentially serious consequences. The Thurlby Thander PLH250-P incorporates S-Lock. One press of the Lock button transfers control of voltage and current from the analog controls to internal digital circuitry. This offers not just complete security, but exceptional stability as well with each setting controlled by an instrumentation quality DAC.

• High performance linear regulated power supplies
• Full digital remote control and read back
• RS-232, USB and LAN (Ethernet), GPIB optional
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Isolated Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density, up to 94W per output
• Manufacturer's part no. Aim-TTi PLH250-P

Not recommended for use as a battery charger.

The Aim-TTi PLH250-P(G) retains the ultra compact format, high power density, and smart analog controls of the PLH250-P(G), but offers voltages up to 250V to cover applications beyond the capabilities of standard bench PSUs and into areas such as magnetics. This particular model is fitted with GPIB (option G) being an (IEEE-488) interface in addition to USB, RS232 and LAN.

The Aim-TTi PLH250-P(G) achieves an exceptional power density for a linear regulated power supply by offering up to 94W from a ¼ rack 3U sized casing. This gives it an unusually small bench footprint taking up less space on a crowded bench. For rack-mount application, up to four units can be mounted into a single slot. Despite its small size and linear regulation, the Thurlby Thandar PLH250-P(G) generates relatively little heat through the use of an advanced phase controlled pre-regulator. This gives it significantly higher energy efficiency than conventional linear regulated designs, particularly when supplying voltages below maximum.

The internal heat-sinks use fan-assisted convection cooling in order to remove the heat with minimal fan noise.

The Aim-TTi PLH250-P(G) includes all of the manual control features of the PLH series, but adds comprehensive remote control facilities. The ultra-compact rack-modular sizing makes it ideally suited to rack mounted system applications, while its user-friendly manual controls are retained for bench top applications. Power output terminals are duplicated on the rear panel for rack mount applications or other situations where rear connection is more appropriate.

• High performance linear regulated power supplies
• Full digital remote control and read back
• RS-232, USB and LAN (Ethernet), GPIB optional
• LAN Interface conforms with LXI standard
• Interfaces are opto-isolated from outputs
• IVI Driver supplied
• Isolated Analog remote control of V and I
• Front and rear terminals
• Selectable remote sense terminals
• Ultra-compact size of quarter-rack 3U
• High power density, up to 94W per output
• Manual control features as per PLH Series
• Manufacturer's part no. Aim-TTi PLH250-P(G)

Not recommended for use as a battery charger.

The Aim-TTi Single QL355 SII offers an unparalleled level of precision. Voltage and current are controlled using instrumentation quality 16-bit DACs enabling voltages to be set to 1mV resolution even at full output voltage. Indeed, the accuracy is sufficient for the QL to be used as a calibration source for some hand-held DMMs.

The Aim-TTi Single QL355 SII provides multiple ranges for increased current capability at lower voltages. The QL355 SII uses pure linear technology and offers unrivalled performance in terms of regulation, output noise and dynamics. Line and load regulation are close to the limit of measurement. Recovery time from transient current pulses is better than 50μs.

Of equal importance for critical applications in areas such as telecoms is common mode noise current (the noise current flowing between the output terminals and ground). This is less than 4μA rms on the QL355 SII dramatically better than most other PSUs.

• Single output or triple output models
• Setting by direct numeric entry or spin wheel
• 1mV resolution at up to 56V
• Multiple ranges for increased current flexibility
• Multiple non-volatile setting memories
• OVP and OCP trips with alarm output
• Selectable remote sense terminals
• Linked-mode operation of main outputs (triple)
• Auxiliary output variable 1.00V to 6.00V at 3A (triple)
• Manufacturer's part no. Aim-TTi QL355 SII

Not recommended for use as a battery charger.

The Aim-TTi QL355P SII offers an unparalleled level of precision. Voltage and current are controlled using instrumentation quality 16-bit DACs enabling voltages to be set to 1mV resolution even at full output voltage.

Indeed, the accuracy is sufficient for the QL to be used as a calibration source for some hand-held DMMs. The QL series uses pure linear technology and offers unrivalled performance in terms of regulation, output noise and dynamics. Line and load regulation are close to the limit of measurement. Recovery time from transient current pulses is better than 50μs. Differential output noise is less than 350μV rms in CV mode and down to 20μA rms in CI mode.

Of equal importance for critical applications in areas such as telecoms is common mode noise current (the noise current flowing between the output terminals and ground). This is less than 4μA rms on the QL Series - dramatically better than most other PSUs.

The user interface of the QL series has been painstakingly designed to provide rapid control whilst guarding against any possibility of error. Unlike other digitally controlled units, the QL series provides both numeric and rotary control. Illuminated keys and display legends provide instant confirmation of settings and status.

• Single output or triple output models, LAN, GPIB, RS232 and USB interfaces
• LAN interface conforms with LXI class C
• Compact modular width for bench or rack, front and rear mounted terminals
• 1mV resolution at up to 56V
• Multiple ranges for increased current flexibility
• Multiple non-volatile setting memories
• OVP and OCP trips with alarm output
• Selectable remote sense terminals
• Full control and read-back of all outputs via the bus
• Not recommended for use as a battery charger.
• Manufacturers part no. Aim-TTi QL355P SII

The QL series uses pure linear technology and offers unrivalled performance in terms of regulation, output noise and dynamics. Line and load regulation are close to the limit of measurement. Recovery time from transient current pulses is better than 50µs. Output noise is less than 350µV rms in CV mode and down to 20µA rms in CI mode, dramatically better than other PSUs

The user interface of the QL series has been painstakingly designed to provide rapid control while guarding against any possibility of error. Unlike other digitally controlled units, the QL series provides both numeric and rotary control. Illuminated keys and display legends provide instant confirmation of settings and status.

For those preferring quasi-analogue control, or for applications where the voltage or current must be gradually changed, the Jog wheel is available. The wheel has a positive stepped action but can be spun rapidly when required. Output voltage can be incremented or decremented in steps of 0.1V, 10mV or 1mV. Current steps can be selected from 0.1A down to 0.1mA. The Jog function can be left permanently engaged or can be disabled at the touch of a button.

• Cooled by temperature-controlled fan
• Simultaneous voltage and current readout
• Voltage and current step less adjustment
• Constant voltage or constant current operation
• Overvoltage protection
• Protection against reverse polarization
• LOCK function (settings lock)
• Coarse and fine voltage adjustment
• Manufacturers part no. Aim-TTi QL355T SII

Not recommended for use as a battery charger.

The Aim-TTi QL355TP SII represents the next generation of high performance laboratory power supplies, maintaining the tradition started with the PL series in 1980 and continued throughout more than two decades.

The Aim-TTi QL355TP SII offers an unparalleled level of precision. Voltage and current are controlled using instrumentation quality 16 bit DACs enabling voltages to be set to 1mV resolution even at full output. Indeed, the accuracy is sufficient for the QL to be used as a calibration source for some hand-held DMMs.

The user interface of the QL series has been painstakingly designed to provide rapid control whilst guarding against any possibility of error. Unlike other digitally controlled units, the QL series provides both numeric and rotary control. Illuminated keys and display legends provide instant confirmation of settings and status.

• Advanced DC power supply range, single or triple output
• Very high precision, very low noise, excellent dynamics
• Advanced user interface with numeric and rotary control
• Multiple voltage/current ranges for increased flexibility
• Multiple non-volatile memories for power supply set-ups
• Switchable remote sense provides perfect load regulation
• Comprehensive protection including OVP and OCP trips
• Compact bench footprint; modular width for rack mounting
• Auxiliary output of 5.0V, 3.3V or 2.7V
• Manufacturer's part no. Aim-TTi QL355TP SII

Not recommended for use as a battery charger.

The Aim-TTi Single QL564 SII offers an unparalleled level of precision. Voltage and current are controlled using instrumentation quality 16-bit DACs enabling voltages to be set to 1mV resolution even at full output voltage. Indeed, the accuracy is sufficient for the QL to be used as a calibration source for some hand-held DMMs.

The Aim-TTi Single QL564 SII provides multiple ranges for increased current capability at lower voltages. The QL564 SII uses pure linear technology and offers unrivalled performance in terms of regulation, output noise and dynamics. Line and load regulation are close to the limit of measurement. Recovery time from transient current pulses is better than 50μs.

Of equal importance for critical applications in areas such as telecoms is common mode noise current (the noise current flowing between the output terminals and ground). This is less than 4μA RMS on the QL564 SII dramatically better than most other PSUs.

• Single output or triple output models
• Setting by direct numeric entry or spin wheel
• 1mV resolution at up to 56V
• Multiple ranges for increased current flexibility
• Multiple non-volatile setting memories
• OVP and OCP trips with alarm output
• Selectable remote sense terminals
• Linked-mode operation of main outputs (triple)
• Auxiliary output variable 1.00V to 6.00V at 3A (triple)
• Manufacturer's part no. Aim-TTi QL564 SII

Not recommended for use as a battery charger.

The Aim-TTi QL564P SII represents the next generation of laboratory power supplies offering an unparalleled level of precision and performance. The voltage and current are controlled using 16-bit DACs enabling voltages to be set to 1mV resolution even at full output. Indeed, the accuracy is sufficient for the PSU to be used as a calibration source for some hand-held DMMs.

The Aim-TTi QL564P SII uses pure linear technology and offers unrivalled performance in terms of regulation, output noise and dynamics. Line and load regulation are at the limit of measurement. Output noise is less than 350µV rms. Recovery time from transient current pulses is better than 50µs.

The QL series provides full remote sense capability via dedicated sense terminals. Remote sense is essential to maintain precise regulation at the load (two 0.03Ω connection leads will drop 300mV at 5A). When remote sense is not required, internal local sensing can be selected at the touch of a button.

• Single output or triple output models
• Setting by direct numeric entry or spin wheel
• 1mV resolution at up to 56V
• Multiple ranges for increased current flexibility
• Multiple non-volatile setting memories
• OVP and OCP trips with alarm output
• Selectable remote sense terminals
• Linked-mode operation of main outputs (triple)
• Auxiliary output of 2.7, 3.3 or 5.0V at 1A (triple)
• Setting memories for added convenience
• Fast, simple, and safe to use
• Compact design for bench or rack
• Manufacturer's part no. Aim-TTi QL564P SII

Not recommended for use as a battery charger.
