The WAGO 1-Way PCB Spring Terminal Block 7.5-7.62mm 16A Grey is a modular PCB terminal with 1 pole/2 solder pins and locking side pin spacing of 7.5-7.62mm/0.3in. Connectable single terminals for WAGO Series 256 PCB's.

The CAGE CLAMP® connection technique allows stripped solid and ferruled conductors to be pushed in. With its space saving design, the terminal block is up to 30% smaller than standard terminal blocks and with a conductor entry angle of less than 15° which allows easier installation in smaller spaces.

• Mounting example: 10 x 73 04 69-07 with end plate 73 05 35-07
• Cage clamp connection
• Grey colour
• 13 x 7.5 x 14mm (H x W x D)

This 2-way PCB push button terminal block from WAGO has a 45° entry angle for easy, space-saving wiring.

• Pitch 7.5mm
• Current rating 17.5A
• Push-in Cage Clamp® termination
• Number of poles 2
• Number of potentials 2
• Colour: grey
• Height 20.5mm
• Width 14mm
• Depth 13mm
• Manufacturer's part 250-602

A 3-way pushbutton PCB terminal block from WAGO with 7.5mm pitch.

• Compact terminal strips
• Simple push-in termination for solid conductors
• Termination/removal of fine-stranded conductors via push-buttons
• 45° conductor entry angle provides easy, space-saving wiring
• CAGE CLAMP® connection
• Colour: grey
• Tin-plated copper alloy contacts
• Height 20.5mm
• Depth 13mm
• Width 21.5mm
• Manufacturer's part 250-603

Compact 2-pole PCB terminal block with push buttons from WAGO.

• Simple, push-in termination of solid and ferruled conductors
• Termination/removal of fine-stranded conductors via push-buttons
• 45° conductor entry angle provides easy, space-saving wiring
• Push-in CAGE CLAMP® connection
• Rated current 17.5A
• Pitch 7.5mm
• Colour: blue
• Height 20.5mm
• Width 21.5mm
• Depth 13mm
• Manufacturer's part 250-603/000-006

This 4-way PCB push button terminal block from WAGO has a 45° entry angle for easy, space-saving wiring.

• Pitch 7.5mm
• Current rating 17.5A
• Push-in Cage Clamp® termination
• Number of poles 4
• Number of potentials 4
• Colour: grey
• Height 20.5mm
• Width 29mm
• Depth 13mm
• Manufacturer's part 250-604

This 6-way PCB push button terminal block from WAGO has a 45° entry angle for easy, space-saving wiring.

• Pitch 7.5mm
• Current rating 17.5A
• Push-in Cage Clamp® termination
• Number of poles 6
• Number of potentials 6
• Colour: grey
• Height 20.5mm
• Width 44mm
• Depth 13mm
• Manufacturer's part 250-606

Compact 10-pole PCB terminal block with push buttons from WAGO.

• Simple, push-in termination of solid and ferruled conductors
• Termination/removal of fine-stranded conductors via push-buttons
• 45° conductor entry angle provides easy, space-saving wiring
• Push-in CAGE CLAMP® connection
• Rated current 17.5A
• Pitch 7.5mm
• Colour: grey
• Height 20.5mm
• Width 74mm
• Depth 13mm
• Manufacturer's part 250-610

Stackable pushbutton terminal block with 1 pole from the WAGO 256 series.

The CAGE CLAMP® connection technique allows stripped solid and ferruled conductors to be pushed in. With its space saving design, the terminal block is up to 30% smaller than standard terminal blocks and with a conductor entry angle of less than 15° allows easier installation in smaller spaces.

• Set to metric or inch pin spacing by compressing terminal strips together or pulling them apart
• Ideal for in-the-field wiring thanks to simplified push-button actuation
• Convenient, tool-free operation
• Grey colour
• Tin-plated electrolytic copper contacts
• Height 22.2mm
• Width 10.3mm
• Depth 17.6mm
• Manufacturer's part 256-501

Stackable pushbutton terminal block with 2 poles from the WAGO 256 series.

The CAGE CLAMP® connection technique allows stripped solid and ferruled conductors to be pushed in. With its space saving design, the terminal block is up to 30% smaller than standard terminal blocks and with a conductor entry angle of less than 15° allows easier installation in smaller spaces.

• Set to metric or inch pin spacing by compressing terminal strips together or pulling them apart
• Ideal for in-the-field wiring thanks to simplified push-button actuation
• Convenient, tool-free operation
• Grey colour
• Tin-plated electrolytic copper contacts
• Height 22.2mm
• Width 17.9mm
• Depth 17.6mm
• Manufacturer's part 256-502

The WAGO 1-Way PCB Spring Terminal Block 7.5mm 32A Grey is a modular PCB terminal block with 2 solder pins/pole 1, pole pin spacing 7.5mm/0.295in. From the WAGO 745 Series with spring-cage connection.

• 745-831
• Grey colour
• CAGE CLAMP®S Connection
• 23 x 7.5 x 29.1mm (H x W x D)

Stackable 1-pole PCB terminal block from WAGO with 45° entry angle.

• Screwdriver-actuated CAGE CLAMP® for custom terminal strip assemblies
• Comb-style jumper bars for commoning and distributing potentials
• Double solder pins for high mechanical stability
• Saves space thanks to positioning of terminal strips behind one another
• Spacers for higher voltage applications
• Integrated testing tap
• Marker slot for miniature WSB and WSM markers
• Pitch 7.5mm
• Rated current 41A
• Colour: blue
• Height 27.5mm
• Width 9mm
• Depth 29.1mm
• Manufacturer's part 745-834

Staggered 2-pole PCB terminal block from WAGO with push-in CAGE CLAMP® connection and push button actuation.

• Large conductor entry accommodates conductors with a cross-section up to 12 AWG with insulation diameter up to 4.2mm
• Rated current 24A
• Pitch 7.5mm
• Colour: grey
• Height 18.1mm
• Width 14mm
• Depth 15mm
• Manufacturer's part 804-302

Staggered 3-pole PCB terminal block from WAGO with push-in CAGE CLAMP® connection and push button actuation.

• Large conductor entry accommodates conductors with a cross-section up to 12 AWG with insulation diameter up to 4.2mm
• Rated current 24A
• Pitch 7.5mm
• Colour: grey
• Height 18.1mm
• Width 21.5mm
• Depth 15mm
• Manufacturer's part 804-303
