Terminal block 6-way, side entry header, 3.81mm pitch, suitable for use in a variety of PCB applications. This plug has been designed with a steel yoke to create a reliable connection suitable for use in industrial controls, information technology and other applications requiring a highly reliable interconnection with the flexibility of simplified modifications and installations.

• Pitch: 3.81 mm
• Rated voltage: UL–300V; IEC–130V
• Rated current: UL–8A; IEC–8A
• Wire size: 1.5mm²
• Solid wire size: 28–16AWG
• Stranded wire range: 28–16AWG
• Rated surge voltage: 1.6/ 1.25/ 3kV
• Torque: 0.2Nm
• Screw: M2
• Wire strip length: 6–7mm

IMO 21.350M/2-E 2 Way 15A 5.08mm PCB Screw Terminal Block

• 21.350M/4-ES
• Terminal Block Standard Vert.
• 5.08mm,4 Way,300V,15A
• Mod.,Rising Clamp Green,Slot Screw
• Pack Size: 100

Free plug 5.08mm pitch terminal blocks with 4 ways that can be used in a variety of PCB applications. The plugs have been designed with a steel yoke to create a reliable connection suitable for use in industrial controls, information technology and other applications requiring a highly reliable interconnection with the flexibility of simplified modifications and installations.Please note: These terminal blocks are supplied in the manufacturer's pack sizes as stipulated in the technical specification. Samples of the range are available on request.

• Rated voltage: UL–300V; IEC–250V
• Rated current: UL–15A; IEC–17.5A
• Wire range: 2.5mm²
• Solid wire size: 28–12AWG
• Stranded wire range: 30–12AWG
• Rated surge voltage: 1.6/ 2/ 4kV
• Torque: 0.5Nm
• Screw: M2.5
• Wire strip length: 7–8mm

Side entry 5.08mm pitch header with 3 ways that can be used in a variety of PCB applications. The plugs have been designed with a steel yoke to create a reliable connection suitable for use in industrial controls, information technology and other applications requiring a highly reliable interconnection with the flexibility of simplified modifications and installations.Please note: These terminal blocks are supplied in the manufacturer's pack sizes as stipulated in the technical specification. Samples of the range are available on request.

• Rated voltage: UL–300V; IEC–250V
• Rated current: UL–15A; IEC–17.5A
• Wire range: 2.5mm²
• Solid wire size: 28–12AWG
• Stranded wire range: 30–12AWG
• Rated surge voltage: 1.6/ 2/ 4kV
• Torque: 0.5Nm
• Screw: M2.5
• Wire strip length: 7–8mm

Side entry 5.08mm pitch header with 4 ways that can be used in a variety of PCB applications. The plugs have been designed with a steel yoke to create a reliable connection suitable for use in industrial controls, information technology and other applications requiring a highly reliable interconnection with the flexibility of simplified modifications and installations.Please note: These terminal blocks are supplied in the manufacturer's pack sizes as stipulated in the technical specification. Samples of the range are available on request.

• Rated voltage: UL–300V; IEC–250V
• Rated current: UL–15A; IEC–17.5A
• Wire range: 2.5mm²
• Solid wire size: 28–12AWG
• Stranded wire range: 30–12AWG
• Rated surge voltage: 1.6/ 2/ 4kV
• Torque: 0.5Nm
• Screw: M2.5
• Wire strip length: 7–8mm

Top entry 5.08mm pitch header with 4 ways that can be used in a variety of PCB applications. The plugs have been designed with a steel yoke to create a reliable connection suitable for use in industrial controls, information technology and other applications requiring a highly reliable interconnection with the flexibility of simplified modifications and installations.Please note: These terminal blocks are supplied in the manufacturer's pack sizes as stipulated in the technical specification. Samples of the range are available on request.

• Rated voltage: UL–300V; IEC–250V
• Rated current: UL–15A; IEC–17.5A
• Wire range: 2.5mm²
• Solid wire size: 28–12AWG
• Stranded wire range: 30–12AWG
• Rated surge voltage: 1.6/ 2/ 4kV
• Torque: 0.5Nm
• Screw: M2.5
• Wire strip length: 7–8mm

This Metway 166G series, 3-pole cable mounting socket complies with EN 60 320 and is primarily intended for use with lighting equipment. Applications include digital dimming and three-phase supplies, especially where limited access requires the use of a low-profile moulding.

The connector has an extended earth plug fitted as standard and can be connected and disconnected under-load in accordance with VDE 0627. It is fully 'touchproof' when coupled or uncoupled. It is supplied complete with cover and base-plate in an unassembled condition.

• Cable-mounting 3-pole socket
• Colour: white
• Mouldings: nylon 6.6 (PA6/6), pastel blue
• Inserts: brass, tinned
• Temperature limits: max short-term: 160°C, continuous: 100°C
• Current rating: to EN 61 984: 16A / 400V at 70°C
• Conductor size: 1.5 to 2.5mm²
• Wire stripping length: 7mm
• Protection class: IP 20, IP 40 when connected
• Metway type 116GBUFW03

This Metway 166G series, 3-pole panel mounting socket complies with EN 60 320 and is primarily intended for use with lighting equipment. Applications include digital dimming and three-phase supplies, especially where limited access requires the use of a low-profile moulding.

The connector has an extended earth plug fitted as standard and can be connected and disconnected under-load in accordance with VDE 0627. It is fully 'touchproof' when coupled or uncoupled. It is supplied complete with cover and base-plate in an unassembled condition.

• Panel-mounting 3-pole socket
• Colour: white
• Mouldings: nylon 6.6 (PA6/6), pastel blue
• Inserts: brass, tinned
• Temperature limits: max short-term: 160°C, continuous: 100°C
• Current rating: to EN 61 984: 16A / 400V at 70°C
• Conductor size: 1.5 to 2.5mm²
• Wire stripping length: 7mm
• Protection class: IP 20, IP 40 when connected
• Metway type 116GBUW03

This Metway 166G series, 3-pole cable mounting plug complies with EN 60 320 and is primarily intended for use with lighting equipment. Applications include digital dimming and three-phase supplies, especially where limited access requires the use of a low-profile moulding.

The connector has an extended earth plug fitted as standard and can be connected and disconnected under-load in accordance with VDE 0627. It is fully 'touchproof' when coupled or uncoupled. It is supplied complete with cover and base-plate in an unassembled condition.

• Cable-mounting 3-pole plug
• Colour: white
• Mouldings: nylon 6.6 (PA6/6), pastel blue
• Inserts: brass, tinned
• Temperature limits: max short-term: 160°C, continuous: 100°C
• Current rating: to EN 61 984: 16A / 400V at 70°C
• Conductor size: 1.5 to 2.5mm²
• Wire stripping length: 7mm
• Protection class: IP 20, IP 40 when connected
• Metway type 116GSTFW03

PCB mounting feed-through headers.

The vertical connection allows multi-row arrangement on the PCB.

• Number of ways: 2
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals

PCB mounting feed-through headers.

The vertical connection allows multi-row arrangement on the PCB.

• Number of ways: 3
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals

PCB mounting feed-through headers.

The vertical connection allows multi-row arrangement on the PCB.

• Number of ways: 4
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals

PCB mounting feed-through headers.

The vertical connection allows multi-row arrangement on the PCB.

• Number of ways: 6
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals

PCB mounting feed-through headers.

The vertical connection allows multi-row arrangement on the PCB.

• Number of ways: 8
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals

PCB mounting feed-through headers.

The vertical connection allows multi-row arrangement on the PCB.

• Number of ways: 10
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals

PCB mounting feed-through headers.

The horizontal style allows connection to be made on the edge of the PCB.

• Number of ways: 2
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 2
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

PCB mounting feed-through headers.

The horizontal style allows connection to be made on the edge of the PCB.

• Number of ways: 3
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 3
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 4
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

PCB mounting feed-through headers.

The horizontal style allows connection to be made on the edge of the PCB.

• Number of ways: 6
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 6
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 7
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

PCB mounting feed-through headers.

The horizontal style allows connection to be made on the edge of the PCB.

• Number of ways: 8
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 8
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 9
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 10
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 11
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 12
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 14
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 16
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 2
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 3
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 4
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 5
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 6
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 7
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 8
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 9
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 10
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 11
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 12
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 13
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 14
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 15
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 16
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 18
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

Cable-mounted plugs ideal for connection to a compatible PCB-mounted socket.

• Number of ways: 24
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Connection method: screw connection with tension sleeve
• Conductor cross-section 2.5mm²
• Colour: green
• Contact surface: tin
• CSA, VDE & UL approvals

PCB mounting feed-through headers.

The vertical style allows connectors to be positioned side-by-side on the PCB.

• Number of ways: 2
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals

PCB mounting feed-through headers.

The vertical style allows connectors to be positioned side-by-side on the PCB.

• Number of ways: 3
• Nominal current: 12A
• Rated voltage (III/2): 320V
• Pitch: 5.08mm
• Colour: green
• Contact surface: Tin
• Mounting: wave soldering
• CSA, VDE & UL approvals
